Product Overview
IBM QSFP+ 40GBASE-ESR4 OPTICAL TRANSCEIVER
The IBM QSFP+ 40GBASE-eSR4 Transceiver module (00FE325) is a QSFP+ 40 Gigabit Ethernet Quad Small Form-Factor-Plus, hot-pluggable transceiver that plugs into a QSFP+ high-speed data port. It provides 40 Gbps optical Ethernet connectivity for up to 300 meters using OM3 multimode fiber (MMF) cable and up to 400 meters using OM4 multimode fiber (MMF) cable. This 40 Gigabit Ethernet transceiver module provides excellent performance in port-dense networks with challenging thermal environments. It also has the capability to breakout into four multimode fiber (MMF) cable with LC duplex connectors (00FM412, 00FM413, 00FM414). The 40GBASE-eSR4 is compliant with 40 Gigabit Ethernet IEEE 802.3ba-2010 (40GBASE-SR4) specifications and per channel basis to the IEEE 802.3ae 10GBASE-SR optical specification.
The IBM MTP-4xLC OM3 MMF Breakout Cables provide the capability to connect the IBM QSFP+ 40GBASE-eSR4 Optical Transceiver to 4 x 10GBase-SR transceivers in the link partner.
The 1U air inlet ducts provide additional cooling to minimize recirculation, if warranted by the installation.
- 40Gigabit Ethernet - Designed to provide high-performance Ethernet connection while minimizing power and CPU cycles' utilization
- With its thicker diameter to carry the light of multiple wavelengths, multi-mode fibre optic cable supports the high bandwidth to carry more information with greater fidelity
- Optical fibre cable compatible - Spans afar and provides speedy data transmission rates between servers and network components
- With 40GBase-eSR4 technology, enjoy up to 40Gbps data transfer rate over optical fibre cable
Technical Specifications
| Package Contents |
|
| Application/Usage | Data Networking |
| Optical Network |
| Interfaces/Ports Details | 1 x LC Duplex 40GBase-eSR4 |
| Connector Type | LC |
| Total Number of Ports | 1 |
| Network Technology | 40GBase-eSR4 |
| Maximum Data Transfer Rate | 40 |
| Ethernet Technology | 40 Gigabit Ethernet |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
| Weight (Approximate) | 44 g |
| Form Factor | Hot-pluggable |
| Height | 12.9 mm |
| Width | 18.4 mm |
| Depth | 132 mm |
| Product Type | Expansion Module |
| Manufacturer Part Number | 00FE325 |
| Manufacturer Website Address | http://www3.lenovo.com/au/en |
| Manufacturer | Lenovo Group Limited |
| Product Name | QSFP+ 40GBase-eSR4 Transceiver for IBM Systems |
| Brand Name | Lenovo |
