Product Overview

SonicWall SuperMassive 9200 Network Security/Firewall Appliance - 8 Port - 10/100/1000Base-T - 10 Gigabit Ethernet, 1000Base-X, 10GBase-X - 15 Gbit/s Firewall Throughput - SSL - 8 x RJ-45 - 13.0 Total Expansion Slots - 1U - Rack-mountable

The SonicWall SuperMassive Series is SonicWall's next-generation firewall (NGFW) platform designed for large networks to deliver scalability, reliability and deep security at multi-gigabit speeds with near zero latency.

Built to meet the needs of enterprise, government, education, retail, healthcare and service provider, the SuperMassive Series is ideal for securing distributed enterprise networks, data centers and service providers.

The combination of SonicWall's SonicOS operating system, patented Reassembly-Free Deep Packet Inspection® (RFDPI) technology and massively multi-core, highly scalable hardware architecture, the SuperMassive 9000 Series deliver industry-leading application control, intrusion prevention, malware protection and TLS/SSL decryption and inspection at multigigabit speeds. The SuperMassive Series is thoughtfully designed with power, space and cooling (PSC) in mind, providing the leading Gbps/watt NGFW in the industry for high performance packet and data processing, application control and threat prevention.

The SonicWall RFDPI engine scans every byte of every packet across all ports, delivering full content inspection of the entire stream while providing high performance and low latency. This technology is superior to proxy designs that reassemble content using sockets bolted to anti-malware programs, which are plagued with inefficiencies and the overhead of socket memory thrashing, which leads to high latency, low performance and file size limitations.

The RFDPI engine delivers full content inspection to eliminate various forms of malware before they enter the network and provides protection against evolving threats - without file size, performance or latency limitations.

The RFDPI engine also performs full decryption and inspection of TLS/SSL and SSH encrypted traffic as well as non-proxyable applications, enabling complete protection regardless of transport or protocol. It looks deep inside every packets (the header and data part) searching for protocol non-compliance, threats, zero-days, intrusions, and even defined criteria to detect and prevent attacks hidden inside encrypted traffic, cease the spread of infections, and thwart command and control (C&C) communications and data exfiltration. Inclusion and exclusion rules allow total control to customize which traffic is subject to decryption and inspection based on specific organizational compliance and/or legal requirements.

Application traffic analytics enable the identification of productive and unproductive application traffic in real time, and traffic can then be controlled through powerful application-level policies. Application control can be exercised on both a per-user and pergroup basis, along with schedules and exception lists. All application, intrusion prevention and malware signatures are constantly updated by the SonicWall Capture Labs threats research team. Additionally, SonicOS, an advanced purpose-built operating system, provides integrated tools that allow for custom application identification and control.

  • Get complete breach prevention including high performance intrusion prevention, low latency malware protection and cloud based sandboxing
  • Gain full granular application identification, control and visualization
  • Find and block hidden threats with decryption and inspection of TLS/ SSL and SSH encrypted traffic, without performance problems
  • Scale security performance for 10/40 Gbps data centers
  • Adapt to service-level increases and ensure network services and resources are available and protected

Technical Specifications

Management & Protocols
ManageableYes
Media & Performance
VPN Throughput640 MB/s
Wireless Specifications
Wireless LANNo
Interfaces/Ports
Number of Network (RJ-45) Ports8
Total Number of Ports8
Power Description
Frequency50 Hz
60 Hz
Power Consumption300 W
Network & Communication
Network Standard1000Base-X
10/100/1000Base-T
10GBase-X
Ethernet Technology10 Gigabit Ethernet
Technical Information
Firewall Protection SupportedTLS Inspection
Deep Inspection Firewall
Intrusion Prevention
Malware Protection
URL Filtering
Application Firewall
TLS Decryption
SSL Inspection
SSL Decryption
Secure IPsec VPN Connectivity
Connectivity TechnologyWired
Encryption StandardSSL
Firewall Throughput15 Gbit/s
Physical Characteristics
Weight (Approximate)8.21 kg
Height44.5 mm
Width485.1 mm
Depth431.8 mm
Miscellaneous
Certifications & Standards
    • FCC Class A
    • ICES Class A
    • CE (EMC, LVD)
    • C-Tick
    • VCCI Class A
    • UL/cUL
    • TUV/GS
    • CB
    • Mexico CoC by UL
    • BSMI
    • KCC/MSIP
    • ANATEL
Environmentally FriendlyYes
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Waste Electrical and Electronic Equipment Directive (WEEE)
Restriction of Hazardous Substances (RoHS)
I/O Expansions
Expansion Slot TypeSFP (mini-GBIC)
SFP+
Expansion Slot
Number of SFP Slots8
Number of SFP+ Slots4
Total Number of Expansion Slots13.0
General Information
Product TypeNetwork Security/Firewall Appliance
Manufacturer Part Number01SSC1062
Manufacturer Website Addresshttp://www.sonicwall.com
ManufacturerSonicWall Inc.
Product Model9200
Product NameSuperMassive 9200 Network Security/Firewall Appliance
Product LineSuperMassive
Product Series9000
Brand NameSonicWall
