AXIS Q6315-LE 50HZ

AXIS Q6315-LE 50HZ

AXIS Q6315-LE 50HZ

Product Overview

AXIS Q6315-LE Outdoor Full HD Network Camera - Colour - Dome - White - 300 m Infrared Night Vision - H.264 (MPEG-4 Part 10/AVC), H.265 (MPEG-H Part 2/HEVC), MJPEG, H.264, H.265 - 1920 x 1080 - 6.91 mm- 214.64 mm Varifocal Lens - 31.1x Optical - 60 fps - CMOS - Corner Mount, Ceiling Mount, Pole Mount, Parapet Mount, Wall Mount, Pendant Mount, Recessed Mount - IK10 - IP66, IP67 - Vandal Resistant, Water Resistant, Dust Resistant, Shock Resistant

Ideal for city surveillance, AXIS Q6315-LE offers a ½" sensor and 31x optical zoom. It features laser focus for precise focus every time - even in the dark. And, Speed Dry functionality for crisp, clear images in rainy weather.

Super surveillance- day and night

AXIS Q6315-LE features very light-sensitive ½" inch sensor to deliver clear, bright images and better handling of shadows even in challenging light conditions. Including IR Illumination and D/N functionality, it's perfect for surveillance in pitch darkness without the need for additional lighting. With 31x optical zoom, a built-in laser, and quick-zoom functionality, AXIS Q6315-LE allows you to easily follow fast-moving objects. Plus, it offers laser focus for precise focus- every time. It's possible to mount this camera in AXIS Q6100-E allowing for continuous 360° rotation for total situational awareness. And, because it uses the same bracket, power supply, and network cable as AXIS Q6100 you get cost-efficient installation. Furthermore, Zipstream with support for H.264 and H.265 significantly lowers bandwidth and storage requirements without compromising image quality

Built-in advanced analytics

This top-of-the-line camera contains all the functionality you need to track and identify suspect behavior. It offers autotracking 2 with click and track functionality for active object tracking. And an orientation aid enables dynamic text overlays with street names and a compass symbol for quick orientation. Where privacy must be kept, privacy masking with mosaic lets you pixelate whole areas such as a neighboring property. Plus, with chameleon masking, it automatically changes the color in the masking depending on the background color of the image.

Keeping you secure

AXIS Q6315-LE includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified to ensure secure storage of all cryptographic keys and certificates. This IK10-rated vandal-resistant camera is protected against the ingress of dust and high pressure water jets from any direction (IP66 rating). It offers shock detection, which allows the camera to send an alarm when it has been hit. And, with support for fiber connection and PoE, it allows for cost-effective installation and long-distance connections.

  • CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
  • For remote surveillance needs, this network camera is best suited
  • Up to 1920 x 1080 resolution for surveillance in real-time
  • Provides night vision of objects at a distance of up to 300 m

Technical Specifications

Interfaces/Ports
Network (RJ-45)Yes
Storage
Storage TypeMemory Card
Exposure
Longest Shutter Speed1/2 Second
Shortest Shutter Speed1/111000 Second
Network & Communication
Connectivity TechnologyWired
Remote ManagementYes
Display & Graphics
Color SupportedColour
Image Sensor TypeCMOS
Field of ViewHorizontal field of view: 60.6°- 2.0° Vertical field of view: 36.5°- 1.1°
Environmental Conditions
Minimum Operating Temperature-50°C
Maximum Operating Temperature50°C
Maximum Operating Humidity100%
Power Description
Input Voltage230 V AC
120 V AC
Power Source TypeAC
PoE
Technical Information
Recording FormatsFull HD
Night VisionYes
HD RecordingYes
Night Vision Distance300 m
Night Vision TypeInfrared
Physical Characteristics
Weight (Approximate)4.80 kg
DurabilityWater Resistant
Dust Resistant
Shock Resistant
Vandal Resistant
Form FactorDome
Mount TypePendant Mount
Parapet Mount
Corner Mount
Ceiling Mount
Recessed Mount
Wall Mount
Pole Mount
Diameter192 mm
Height261 mm
Product ColorWhite
Color FamilyWhite
General Information
Product TypeNetwork Camera
Manufacturer Part Number01924-006
Manufacturer Website Addresshttp://www.axis.com/au/en/
ManufacturerAxis Communications
Product ModelQ6315-LE
Product NameQ6315-LE PTZ Network Camera
Brand NameAXIS
Lens
Lens TypeVarifocal
Optical Zoom31.1x
Maximum Aperturef/1.36
Maximum Focal Length214.64 mm
Minimum Focal Length6.91 mm
Minimum Aperturef/4.6
Lens IncludedYes
Video
Video FormatsH.264
H.265 (MPEG-H Part 2/HEVC)
MJPEG
H.264 (MPEG-4 Part 10/AVC)
H.265
Maximum Video Resolution1920 x 1080
Maximum Frame Rate60 fps
Miscellaneous
Package Contents
  • Q6315-LE PTZ Network Camera
  • Installation Guide
  • Windows decoder 1-user license
  • 60 W Midspan (including power cable)
  • IP66 Rated Network Connector
  • Repaint Template
  • Paint Paper
FeaturesDay/Night
Motion Detection
Password Protection
Privacy Masking
Shock Detection
HTTPS Encryption
Built-in Infrared Illuminator
Auto Tracking
Wide Dynamic Range
SD Card Local Storage
Indoor/OutdoorOutdoor
Impact Protection RatingIK10
Ingress Protection RatingIP66
IP67
