QSFP+ - Brocade 40G-QSFP-SR4 Compatible
QSFP+ - Brocade 40G-QSFP-SR4 Compatible
Product Overview
StarTech.com 40G-QSFP-SR4-ST QSFP+ - 1 x MPO 40GBase-SR4 Network - 1 Pack - For Data Networking, Optical Network - Optical Fiber - Multi-mode - 40 Gigabit Ethernet - 40GBase-SR4 - Hot-swappable
The 40G-QSFP-SR4-ST is a Brocade 40G-QSFP-SR4compatible fiber transceiver module that has been designed, programmed and tested to work with Brocade brand switches and routers. It delivers dependable 40 GbE connectivity over fiber cable, for 40GBase-SR4 compliant networks, with a maximum distance of up to 150 m (492 ft.).
Technical Specifications:
- Wavelength: 850nm
- Maximum Data Transfer Rate: 40 Gbps
- Type: Multi Mode Fiber
- Connection Type: MPO
- Maximum Transfer Distance: 150 m (492 ft.)
- MTBF: 244,610,583 hours
- Power Consumption: Low power consumption
- Digital Diagnostics Monitoring (DDM): Yes
This QSFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPsAll StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
- 40 Gigabit Ethernet for efficient data transfer and fast connectivity
- With its thicker diameter to carry the light of multiple wavelengths, multi-mode fibre optic cable supports the high bandwidth to carry more information with greater fidelity
- Optical fibre cable compatible - Spans afar and provides speedy data transmission rates between servers and network components
- With 40GBase-SR4 technology, enjoy up to 40Gbps data transfer rate over optical fibre cable
Technical Specifications
| Total Number of Ports | 1 |
| Product Type | QSFP+ |
| Manufacturer Part Number | 40G-QSFP-SR4-ST |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Model | 40G-QSFP-SR4-ST |
| Product Name | Brocade QSFP+ Module |
| Brand Name | StarTech.com |
| Compatibility | MSA Compliant |
| Application/Usage | Data Networking |
| Optical Network |
| Network Technology | 40GBase-SR4 |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Multi-mode |
