M.2 5100 240GB SATA SSD
M.2 5100 240GB SATA SSD
Product Overview
M.2 5100 240GB SATA SSD
M.2 is a solid-state drive (SSD) form factor primarily used as an operating system boot solution. Lenovo ThinkSystem servers support M.2 drives either with the addition of a supported M.2 adapter or directly on the system board.
On the ThinkSystem SR150, SR250 and ST250, a single M.2 drive is installed directly on the system board.
On all other support ThinkSystem servers, the M.2 drives install into an M.2 adapter which in turn is installed in a dedicated slot on the system board of the server. With two M.2 drives configured, the drives are configured by default as a RAID-1 mirrored pair for redundancy.
There are two M.2 adapters supported:
- Single M.2 Adapter, which supports one M.2 drive; available as the ThinkSystem M.2 Enablement Kit
- Dual M.2 Adapter, which supports one or two M.2 drives; available as the ThinkSystem M.2 with Mirroring Enablement Kit
- Have data stored faster with SATA/600 interface that optimizes burst performance
- The high-read speed of 540 MB/s maximizes system performance and saves time while you are doing complex tasks
- With the high-write speed of 250 MB/s, get a quick response when updating or transferring files
- Provides sufficient storage capacity of 240 GB for your computer
Technical Specifications
| Wireless LAN | No |
| Storage Capacity | 240 GB |
| Drive Interface | SATA |
| Drive Interface Standard | SATA/600 |
| Compatibility |
|
| Device Supported | Server |
| Product Type | Solid State Drive |
| Manufacturer Part Number | 4XB7A14049 |
| Manufacturer Website Address | http://www3.lenovo.com/au/en |
| Manufacturer | Lenovo Group Limited |
| Product Name | ThinkSystem M.2 5100 240GB SATA 6Gbps Non-Hot Swap SSD |
| Product Series | 5100 PRO |
| Brand Name | Lenovo |
| Maximum Read Transfer Rate | 540 MB/s |
| Maximum Write Transfer Rate | 250 MB/s |
| Endurance (DWPD) | 1.5 |
| Endurance (TBW) | 650 TB |
| Endurance Type | Read Intensive |
| Hot Swappable | No |
| Drive Type | Internal |
| Form Factor | M.2 2280 |
| Width | 22 mm |
| Depth | 80 mm |
