4XB7A90102
Product Overview
ThinkSystem M.2 PM9A3 960GB Read Intensive NVMe PCIe 4.0 x4 NHS SSD
The ThinkSystem PM9A3 Read Intensive NVMe Solid-State Drives (SSDs) are general-purpose yet high-performance family of NVMe SSDs. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads.
This product guide provides essential presales information to understand the ThinkSystem PM9A3 Read Intensive NVMe SSDs offerings and their key features, specifications, and compatibility. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the PM9A3 SSDs and consider their use in IT solutions.
- The high-read speed of 5000 MB/s maximizes system performance and saves time while you are doing complex tasks
- Write speed of 1400 MB/s enables you to perform write-related tasks in seconds rather than minutes
- With a capacity of 960 GB, you have large storage space for all your documents and data
- PCI Express NVMe 4.0 x4 interface provides quick data transfer and greater throughput
Technical Specifications
| Storage Capacity | 960 GB |
| Drive Interface | PCI Express NVMe |
| Drive Interface Standard | PCI Express NVMe 4.0 x4 |
| Compatibility |
Lenovo ThinkSystem Servers: |
| Device Supported | Server |
| Maximum Read Transfer Rate | 5000 MB/s |
| Maximum Write Transfer Rate | 1400 MB/s |
| Random 4KB Read | 550000IOPS |
| Random 4KB Write | 60000IOPS |
| Endurance (DWPD) | 1 |
| Endurance (TBW) | 1752 TB |
| Endurance Type | Read Intensive |
| Weight (Approximate) | 9 g |
| Drive Type | Internal |
| Form Factor | M.2 22110 |
| Length | 110 mm |
| Width | 22 mm |
| Product Type | Solid State Drive |
| Manufacturer Part Number | 4XB7A90102 |
| Manufacturer Website Address | http://www3.lenovo.com/au/en |
| Manufacturer | Lenovo Group Limited |
| Product Name | ThinkSystem M.2 PM9A3 960GB Read Intensive NVMe PCIe 4.0 x4 NHS SSD |
| Product Series | PM9A3 |
| Brand Name | Lenovo |
