5E G2 UPS 2200VA/1200W 3 ANZ OUTLET FAN
5E G2 UPS 2200VA/1200W 3 ANZ OUTLET FAN
Product Overview
Eaton Line-interactive UPS - 2.20 kVA/1.20 kW - Tower - AVR - 120 V AC, 230 V AC Input - 257 V AC, 195 V AC, 240 V AC Output - 3 x AU, 3 x IEC 60320 C13 - Single Phase - LED Display
Eaton 5E Gen2 UPS
The Eaton 5E Gen2 UPS combines proven high performance and quality with affordable pricing to offer cost-effective, reliable protection against power outages and bad power quality. Suitable for home use or for equipment in small business and professional environments, this latest version of our 5E line interactive UPS now also offers national outlets flexibility plus the convenience of permanently recharged batteries (even when off) and the ability to start without mains power (cold start).
CE certification by the external TUV agency guarantees compliance with the latest international safety standards.
Easy application connection and protection
A perfect fit for any local plug type thanks to national outlet formats. Eaton's 5E Gen2 UPS offers single-product simplicity in multiple residential and commercial environments.
Greater tolerance of grid fluctuations
All kinds of influences can upset grid voltage at any time. Features double-boost line interactive topology (AVR) for wider input voltage window (under and overvoltage: 140 - 300 V) to save battery power in the event of power outage.
Silent operation for a better customer experience
A key consideration in residential settings to ensure peace of mind as noisy equipment can distract - as well as add to stress levels. Thanks to a fanless design on all models up to 1200 VA, the 5E Gen2 UPS guarantees silent operation.
- Experience higher efficiency with lower energy cost
- 2.20 kVA load capacity provides sufficient backup during power failures
- 1.20 kW load capacity - backup power for your valuable electronics
Technical Specifications
Display | LED |
USB (HID Compliant) Port | Yes |
Sound Emission | 40 dB |
Maximum Operating Temperature | 40°C |
Battery Chemistry | Sealed Lead Acid (VRLA) |
Battery Size | 12V |
Battery Capacity | 9000 mAh |
Number of Batteries | 2.0 |
Package Contents |
|
Environmentally Friendly | Yes |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
Restriction of Hazardous Substances (RoHS) | |
Battery Directive |
Application/Usage | Residential |
Home | |
Equipment | |
Commercial | |
Business | |
Plug/Connector Type | MISSING_TRANSLATION_IN_TAS |
Phase | Single Phase |
Receptacle Type | IEC 60320 C13 |
AU | |
AVR | Yes |
Receptacle Detail | 3 x IEC 60320 C13 |
3 x AU |
Weight (Approximate) | 9.80 kg |
Height | 180 mm |
Width | 133 mm |
Depth | 330 mm |
Product Color | Black |
Color Family | Black |
Product Type | Line-interactive UPS |
Manufacturer Part Number | 5E2200UIAU |
Manufacturer Website Address | http://www.eatoncorp.com.au |
Packaged Quantity | 1 |
Manufacturer | Eaton Corporation |
Product Name | 5E 2200VA Tower UPS |
Product Series | 5E |
Brand Name | Eaton |
Input Voltage | 230 V AC |
120 V AC | |
Output Voltage | 195 V AC |
240 V AC | |
257 V AC | |
Input Voltage Range | 140 V AC - 300 V AC |
Output Frequency | 60 Hz |
Input Frequency | 65 Hz |
Load Capacity (VA) | 2.20 kVA |
Load Capacity (Watt) | 1.20 kW |
