Eaton 5P 650VA / 420W Tower UPS with LCD
Eaton 5P 650VA / 420W Tower UPS with LCD
Product Overview
Eaton Line-interactive UPS - 650 VA/420 W - 1U Tower - 2 Minute Stand-by - 220 V AC Input - 220 V AC Output - 3 x IEC 60320 C13 - Serial Port - USB
The Eaton 5P is a Line interactive, density optimised (up to 1550VA in 1U) power protection for IT & Telecom environment. Wide power management capabilities offering point-to-point and network supervision.- Experience higher efficiency with lower energy cost
- Up to 2 minute runtime on full load to preserve critical data from power shortage interruptions
- 650 VA load capacity provides sufficient backup during power failures
- Prevent critical data loss by staying powered during a blackout with up to 420 W load capacity
Technical Specifications
Environmental Conditions
| Maximum Operating Temperature | 35°C |
| Sound Emission (A-Weighted) | 40 dB(A) |
Management
| Battery Management | ABM® & temperature compensated charging method (user selectable) |
| Network Management | SNMP Manageable |
Miscellaneous
| Package Contents |
|
| Certifications & Standards |
|
Battery Information
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 9 Minute |
| Backup/Run Time (Full Load) | 2 Minute |
Interfaces/Ports
| USB | Yes |
| Serial Port | Yes |
| Total Number of Expansion Slots | 1 |
General Information
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | 5P650AU |
| Manufacturer Website Address | http://www.eatoncorp.com.au |
| Manufacturer | Eaton Corporation |
| Product Name | 5P 650 VA AU Tower |
| Product Series | 5P |
| Brand Name | Eaton |
Physical Characteristics
| Weight (Approximate) | 7.80 kg |
| Rack Height | 1U |
| Height | 230 mm |
| Width | 150 mm |
| Depth | 345 mm |
Technical Information
| Dataline Protection | USB |
| RS-232 | |
| Plug/Connector Type | Aust. 10A |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 3 x IEC 60320 C13 |
Power Description
| Input Voltage | 220 V AC |
| Output Voltage | 220 V AC |
| Input Current | 10 A |
| Waveform Type | Sine Wave |
| Output Current | 10 A |
| Load Capacity (VA) | 650 VA |
| Load Capacity (Watt) | 420 W |
Price Trend
Current Price
AUD 823.06
