EATON 5SC 1500i
EATON 5SC 1500i
Product Overview
Eaton 5SC1500I Line-interactive UPS - 1.50 kVA/1.05 kW - Tower - 5 Minute Stand-by - 230 V AC Input - 240 V AC Output - 8 x IEC 60320 C13 - Serial Port - USB
Eaton 5SC UPS provides line-interactive, affordable and reliable protection for small business servers. Complementing our range of industry leading UPSs, the 5SC includes an LCD interface for real-time status and measurements, and provides sinewave output for compatibility with today’s most sensitive IT equipment.- Works adequately in situations where the supply is prone to sags and surges
- Keep your sensitive devices powered with a backup of up to 5 minute at full load
- 1.50 kVA load capacity - work without any interruption during power outages
- Prevent critical data loss by staying powered during a blackout with up to 1.05 kW load capacity
Technical Specifications
Management
| Battery Management | ABM |
Miscellaneous
| Certifications & Standards |
|
Battery Information
| Backup/Run Time (Half Load) | 13 Minute |
| Backup/Run Time (Full Load) | 5 Minute |
Environmental Conditions
| Sound Emission | 40 dB |
| Maximum Operating Temperature | 35°C |
Interfaces/Ports
| USB | Yes |
| Serial Port | Yes |
Power Description
| Input Voltage | 230 V AC |
| Output Voltage | 240 V AC |
| Waveform Type | Pure Sine Wave |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (Watt) | 1.05 kW |
Physical Characteristics
| Weight (Approximate) | 15.20 kg |
| Height | 210 mm |
| Width | 150 mm |
| Depth | 410 mm |
| Product Color | Black |
| Color Family | Black |
Technical Information
| Dataline Protection | USB |
| RS-232 | |
| Protection Type | Deep Discharge |
| Plug/Connector Type | IEC 60320 C14 |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 8 x IEC 60320 C13 |
General Information
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | 5SC1500I |
| Manufacturer Website Address | http://www.eatoncorp.com.au |
| Manufacturer | Eaton Corporation |
| Product Model | 5SC1500I |
| Product Name | 5SC 1500 VA Tower |
| Product Series | 5SC |
| Brand Name | Eaton |
