93T 20KVA 400V 12 MIN RT 2X36X34W INT BA

Eaton Double Conversion Online UPS - 20 kVA/20 kW - Three Phase - Tower - 380 V AC, 400 V AC, 415 V AC Input - 380 V AC, 400 V AC, 415 V AC Output - Serial Port - USB

A cost-effective, reliable and flexible three-phase monolithic transformer-free UPS solution | Product values

• Provide a reliable, easy-tomaintain power protection system for small and medium applications
• Free customers from restrictions of expense, space and lacking professional maintenance personnel/ technology experts by providing low TCO (total cost of ownership) and superior performance

Typical applications

• Network centers of the government facilities and educational institutions
• Information & Technology centers of small and medium enterprises
• Data centers of financial institutions such as banks and securities companies

Eaton 93T features | The high-availability and easy-to-maintain transformer-free UPS creates a reliable power protection system for IT installations and mission critical applications

• AReal-time monitoring of the capacitor status eliminates potential safety issues that may happen when capacitors operating under high temperature
• Eaton ABM intelligent battery management technology effectively extends the battery life by more than 50%
• Module-level maintenance enables low MTTR

The cost-effective and high-efficient power supply solution optimizes customer initial investment cost and whole-lifecycle operating costs

• Energy utilization efficiency improves. By adopting three-level topology and industry-leading high-efficient technology, the efficiency can be maintained above 96% under typical load rates
• Up to 99% efficiency can be achieved in ESS mode; it can also be achieved under parallel configuration. This ensures that the UPS can achieve higher system availability while providing reliable power in high quality
• Unity output power factor (utmost active power possible), which enables 100% utilization rate of system capacity

Flexibly adapt to business development and energy storage system upgrades

• The built-in Eaton Hot-sync parallel function provides parallel capability for redundancy and capacity with easy software configuration
• Powerful charger can provide charging power up to 55% of the rated power of the UPS to increase its ability to manage longer back-up time and Lithium-ion battery system

Lithium-ion battery compatible UPS solution | Power on demand

Eaton's lithium-ion battery systems provide a reliable and flexible solution that ensures 24/7 system uptime while delivering significant total cost of ownership (TCO) savings. Capable of providing mega-watts of power in a small footprint, this battery solution comprises of lightweight battery strings designed to seamlessly connect to 93PR 15- 80kVA UPS.

Why lithium?

Lithium-ion chemistry demonstrates superior characteristics in UPS applications, this results in high energy density, long life, flexible installation, improved cycle life and a lower TCO.

Backup battery runtimes

Contact Eaton for backup times and configurations. A wide range of runtimes from 3 minutes to an hour + are available.

Management and monitoring system

The lithium-ion battery integrates a powerful battery management system (BMS), providing cell protection (temp, current, over/ under voltage), cell balancing, state of charge and health and alarms/reports.
