Eaton 9SX 6000VA/5400W On Line Tower UPS
Eaton 9SX 6000VA/5400W On Line Tower UPS
Product Overview
Eaton Double Conversion Online UPS - 6 kVA/5.40 kW - Tower - 230 V AC Input - 200 V AC, 208 V AC, 220 V AC Output - Serial Port
Eaton 9SX (700VA-6kVA) UPS
The Eaton 9SX UPS offers high availability, flexibility and advanced protection for infrastructure, industrial, medical, IT, networking, storage and telecom. Delivering on-line double conversion protection in convenient tower or rack format
- Online double conversion topology allowing for continuous monitoring of power conditions.
- With a 0.9 power factor the 9SX powers more servers than other UPSs with equivalent VA ratings and lower power factors.
- Energy metering - kWh values can be monitored using the LCD or Eaton's Intelligent Power Manager
- Load segment control enables prioritised shutdowns of nonessential equipment to maximise battery runtime for critical devices.
- Eaton ABM battery management technology uses an innovative three-stage charging technique that extends battery life by up to 50%
- Add up to 4 external hot-swappable battery modules for increased battery runtime.
- Easy integration within Virtual environment (VMware, HyperV, RedHat, Citrix)
Technical Specifications
Controls/Indicators
| Status Indicators |
|
Management
| Network Management | SNMP Manageable |
Environmental Conditions
| Sound Emission | 46 dB |
| Maximum Operating Temperature | 40°C |
Interfaces/Ports
| Serial Port | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
Physical Characteristics
| Weight (Approximate) | 65.50 kg |
| Height | 575 mm |
| Width | 244 mm |
| Depth | 542 mm |
Technical Information
| Application/Usage | IT System |
| Medical | |
| Network | |
| Storage Device | |
| Telecommunication | |
| Industry | |
| Plug/Connector Type | Hardwired |
| Receptacle Type | Hardwired |
General Information
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | 9SX6KI-AU |
| Manufacturer Website Address | http://www.eatoncorp.com.au |
| Manufacturer | Eaton Corporation |
| Product Name | 9SX 6000VA Tower UPS |
| Product Series | 9SX |
| Brand Name | Eaton |
Power Description
| Input Voltage | 230 V AC |
| Output Voltage | 220 V AC |
| 230 V AC | |
| 208 V AC | |
| 200 V AC | |
| 240 V AC | |
| Input Voltage Range | 120 V AC - 276 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 70 Hz |
| Load Capacity (VA) | 6 kVA |
| Load Capacity (Watt) | 5.40 kW |
