DELL SMART-UPS DLT1500IC
DELL SMART-UPS DLT1500IC
Product Overview
Dell Smart-UPS Line-interactive UPS - 1.50 kVA/1 kW - Tower - 3 Hour Recharge - 7 Minute Stand-by - 230 V AC Input - 230 V AC Output - 8 x IEC 60320 C13
Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices. Includes: Cat 5 ethernet cable, Installation guide, USB cable
- Cold-start capable - Provides temporary battery power when the utility power is out.
- Energy meter - Provides actual kilowatt hours of usage for energy conscious users.
- Green mode - Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- High online efficiency - Reduces utility costs, generates less heat.
- Intuitive LCD interface - Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
- Predictive replace battery date - Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
- Pure sine wave output on battery - Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Single switched outlet group - Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- SmartConnect - Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services.
- SmartSlot - Customize UPS capabilities with management cards.
- Temperature-compensated battery charging - Prolongs battery life by regulating the charge voltage according to battery temperature.
- Experience higher efficiency with lower energy cost
- Up to 7 minute runtime on full load to preserve critical data from power shortage interruptions
- 1.50 kVA load capacity - work without any interruption during power outages
- 1 kW load capacity - backup power for your valuable electronics
Technical Specifications
Controls/Indicators
| Status Indicators | LCD Display |
Environmental Conditions
| Maximum Operating Temperature | 40°C |
| Sound Emission (A-Weighted) | 45 dB(A) |
Interfaces/Ports
| Network (RJ-45) | Yes |
| USB (HID Compliant) Port | Yes |
Management
| Network Management | SmartSlot |
| Alarm | Alarm |
Miscellaneous
| Package Contents |
|
| Environmentally Friendly | Yes |
Battery Information
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Half Load) | 23 Minute |
| Backup/Run Time (Full Load) | 7 Minute |
| Battery Characteristics | Maintenance-free, Sealed, Leak-proof |
| Typical Battery Recharge Time | 3 Hour |
Technical Information
| Application/Usage | Switch |
| Router | |
| POS Terminal | |
| Network Hub | |
| Network Device | |
| Plug/Connector Type | IEC 60320 C14 |
| Receptacle Type | IEC 60320 C13 |
| Receptacle Detail | 8 x IEC 60320 C13 |
Physical Characteristics
| Weight (Approximate) | 24.09 kg |
| Height | 219 mm |
| Width | 171 mm |
| Depth | 439 mm |
| Product Color | Black |
| Color Family | Black |
General Information
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | AA869894 |
| Manufacturer Website Address | http://www.dell.com.au |
| Manufacturer | Dell Technologies |
| Product Name | Smart-UPS 1500VA Tower UPS |
| Product Line | Smart-UPS |
| Brand Name | Dell EMC |
Power Description
| Input Voltage | 230 V AC |
| Output Voltage | 230 V AC |
| Surge Energy Rating | 459 J |
| Waveform Type | Sine Wave |
| Input Voltage Range | 151 V AC - 302 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 60 Hz |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (Watt) | 1 kW |
