ACB-ISP
Product Overview
| Mechanical | |
|---|---|
| Dimensions | 87.8 x 89.5 x 89.25 mm (3.5 x 3.5 x 3.5") |
| Weight | 280 g (9.9 oz) |
| Hardware | |
| Networking interface | 10/100 Fast Ethernet ports |
| Management interface | Ethernet WiFi |
| Power method | Micro-USB adapter (Not included) PoE 24V In on LAN port 1 |
| Power supply | 5V |
| Max. power consumption | 5W |
| Supported power voltage | 4.95–5.05V |
| PoE Out | Controllable 24V PoE Out (4, 5+, 7, 8-) on WAN port |
| Operating frequency | 2.4 GHz |
| Antenna gain | 4 dBi |
| Max. speeds | 300 Mbps |
| Max. TX power | 20 dBm |
| ESD/EMP protection | ± 24 kV RJ45 interface |
| LED | Status |
| Ambient operating temperature | -10 to 50° C (14 to 122° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | 87.8 x 89.5 x 89.25 mm (3.5 x 3.5 x 3.5") |
| Weight | 280 g (9.9 oz) |
| Hardware | |
| Networking interface | 10/100 Fast Ethernet ports |
| Management interface | Ethernet WiFi |
| Power method | Micro-USB adapter (Not included) PoE 24V In on LAN port 1 |
| Power supply | 5V |
| Max. power consumption | 5W |
| Supported power voltage | 4.95–5.05V |
| PoE Out | Controllable 24V PoE Out (4, 5+, 7, 8-) on WAN port |
| Operating frequency | 2.4 GHz |
| Antenna gain | 4 dBi |
| Max. speeds | 300 Mbps |
| Max. TX power | 20 dBm |
| ESD/EMP protection | ± 24 kV RJ45 interface |
| LED | Status |
| Ambient operating temperature | -10 to 50° C (14 to 122° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
