2.4GHz 2dBi 5GHz 4dBi Ceiling Mount Omni
2.4GHz 2dBi 5GHz 4dBi Ceiling Mount Omni
Product Overview
2.4GHZ 2DBI/5GHZ 4DBI CEILING MOUNT OMNI ANT. 4-PORTRP-TNC
The next generation of Cisco Aironet 802.11n access points - the Cisco Aironet 3600e Series and 1550 Series - requires the use of dual-band external antennas to make them fully functioning units. As these access points take greater advantage of the multiple-input multiple-output (MIMO) features supported under the 802.11n standard, the number of radio transceivers per frequency band has increased. Using dual-band antenna ports allows the access point to support these added transceivers while maintaining a reasonably low number of antenna connections. Each dual-band antenna can transmit or receive Wi-Fi signals in both the 2.4-GHz and 5-GHz bands simultaneously.
Technical Specifications
| Number of Connectors | 4 |
| Additional Information | Cable Length: 3ft. (91.4 cm) Plenum Rated |
| Application/Usage | Wireless Data Network |
| Compatibility |
Cisco Aironet Access Points: |
| Polarization | Linear |
| Directivity | Omni-directional |
| Frequency Band Type | SHF |
| UHF | |
| Operating Frequency Range | 2.4 GHz to 2.484 GHz |
| 5.15 GHz to 5.85 GHz |
| Product Type | Antenna |
| Manufacturer Part Number | AIR-ANT2524V4C-R= |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Name | Aironet Antenna |
| Product Line | Aironet |
| Brand Name | Cisco |
