Product Overview
APC by Schneider Electric PDU - IEC 60309 16A 2P+E - 3 x IEC 60320 C19, 21 x IEC 60320 C13 - 230 V AC Input - 230 V AC Output - Rack-mountable
APC Metered by Outlet with Switching Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and individual outlet power metering. Remote outlet level controls allow power on/off functionality for power recycling to reboot locked-up equipment and to avoid unauthorized use of individual outlets. Power sequencing delays allow users to define the order in which to power up or down attached equipment. Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding. Current metering provides real-time remote monitoring of connected loads. Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles. User-defined alarms warn of potential circuit overloads before critical IT failures occur. Users can access, configure, and control Switched rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager.
Technical Specifications
Management |
Protocols: |
Package Contents |
|
Environmentally Friendly | Yes |
Product Type | PDU |
Manufacturer Part Number | AP8659EU3 |
Manufacturer Website Address | http://www.schneider-electric.com.au |
Manufacturer | Schneider Electric SA |
Product Name | Metered-by-Outlet Rack 24-Outlets PDU |
Brand Name | APC by Schneider Electric |
Weight (Approximate) | 6.77 kg |
Mount Type | Rack-mountable |
Input Voltage | 230 V AC |
Output Voltage | 230 V AC |
Plug/Connector Type | IEC 60309 16A 2P+E |
Receptacle Type | IEC 60320 C13 |
IEC 60320 C19 | |
Receptacle Detail | 21 x IEC 60320 C13 |
3 x IEC 60320 C19 |
