Product Overview
APC by Schneider Electric NetShelter SX 45U Rack Cabinet - 482.60 mm Rack Width - Black - 1020.58 kg Dynamic/Rolling Weight Capacity - 1360.78 kg Static/Stationary Weight Capacity
Feature-rich rack enclosure optimized for easy installation, managing cables, integrating power distribution, and maximizing airflow. Includes: Baying hardware, Key(s), Keyed-alike doors and side panels, Leveling feet, Mounting hardware, Pre-installed casters, Side panels. Split rear doors improve access and serviceability to rear of rack mounted equipment. The split rear doors help to maximize floor space. Only 11 inches (279 mm) of clearance is required behind the enclosures to allow for door swing. Enclosures include pre-installed joining hardware to join enclosures in a row and provide additional stability to the enclosure. Enclosures are shipped standard with both leveling feet and castors. Leveling feet can be quickly adjusted through the use of a screwdriver or drill, eliminating the need to reach underneath with a wrench. Integrated and adjustable rear accessory channel provides zero U mounting locations for toolless accessories. Each channel has two mounting bays to support a combination of up to four accessories such as PDUs and vertical cable organizers. Enclosures with shock packaging are standard enclosures with provisions in the packaging design and enclosure assembly for shipping the enclosures with equipment mounted inside.- Rack Cabinet allows quick and easy retrieval of your items with better organising and feasible mounting
- Comes in black colour for a sophisticated and dassling loo
Technical Specifications
General Information
Product Type | Rack Cabinet |
Manufacturer Part Number | AR3355 |
Manufacturer Website Address | http://www.schneider-electric.com.au |
Manufacturer | Schneider Electric SA |
Product Name | NetShelter SX Enclosure Rack Cabinet |
Product Line | NetShelter SX |
Brand Name | APC by Schneider Electric |
Miscellaneous
Additional Information |
|
Green Premium | Yes |
Product Take Back Program | Yes |
RoHS Exemption Information | https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AR3355_ROHS_DECLARATION&p_FileName=AR3355KIT_ROHS_DECLARATION_US.pdf |
REACH Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=323194534&lang=en-us |
EU RoHS Declaration URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=323194534&lang=en-us |
Environmental Profile Availability | https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512008 |
End of Life Manual Availability | https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512008_EN |
REACH free of SVHC | No |
Physical Characteristics
Weight (Approximate) | 169 kg |
Units Per Pallet | 1 |
Rack Width | 482.60 mm |
Rack Height | 45U |
Height | 2124 mm |
Width | 750 mm |
Depth | 1200 mm |
Rail Material Gauge | 14 |
Door Material Gauge | 18 |
Roof/Top Material Gauge | 18 |
Side Panel Material Gauge | 18 |
Static/Stationary Weight Capacity | 1360.78 kg |
Dynamic/Rolling Weight Capacity | 1020.58 kg |
Product Color | Black |
Color Family | Black |
