Product Overview
Cisco Business Edition 7000H (M6) Appliance Export Restr SW
Scalable collaboration for enterprises
Empower your employees to engage and innovate anywhere, on any device, any time, with industry-leading technology. Cisco Business Edition 7000 is an all-in-one, end-to-end collaboration solution designed for fast-growing enterprises.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- RAID provides data reliability, fault tolerance and improves overall performance through RAID levels (0, 1, 5, 6, 10, 50, 60, JBOD)
- 1.05 kW power supply unit (PSU) fulfils your system's power requirements
- With 192 GB memory, users can run multiple programs simultaneously without losing performance
- 14.40 TB HDD provides you with enough space to store all your documents and multimedia content
Technical Specifications
Chipset
| Chipset Manufacturer | Intel |
| Chipset Model | C621A |
Display & Graphics
| Graphics Memory Capacity | 8 MB |
| Graphics Memory Technology | DDR SDRAM |
Controllers
| RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
Storage
| Hard Drive Interface | 12Gb/s SAS |
| Number of Hard Drives | 16 |
| Total Hard Drive Capacity | 14.40 TB |
| Hard Drive Configuration | 24 x 600GB |
I/O Expansions
| "Number of Internal 2.5"" Bays" | 28 |
| Number of Total Expansion Bays | 28 |
| Total Number of Expansion Slots | 3.0 |
| Hot Swappable Bays | Yes |
| Number of SFF Bays | 28 |
Physical Characteristics
| Form Factor | Rack |
| Rack Height | 2U |
| Height | 86.4 mm |
| Width | 429.3 mm |
| Depth | 762 mm |
General Information
| Product Type | Server |
| Manufacturer Part Number | BE7HM6K9 |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 7000H M6 |
| Product Name | Business Edition 7000H M6 Server |
| Product Line | Business Edition |
| Product Series | 7000 |
| Brand Name | Cisco |
Memory
| Error Checking | ECC |
| Standard Memory | 192 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 12 |
| Intel Optane Memory Ready | Yes |
| Memory Clock Speed | 3.20 GHz |
Power Description
| Power Source | Power Supply |
| Number of Power Supplies Supported | 2 |
| Number of Power Supplies Installed | 2 |
| Redundant Power Supply | Yes |
| Hot Swappable Power Supply | Yes |
| Maximum Power Supply Wattage | 1.05 kW |
Interfaces/Ports
| VGA | Yes |
| Number of Network (RJ-45) Ports | 6 |
| Network (RJ-45) | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 2 |
| Number of USB 3.0 Ports | 2 |
| Number of VGA Ports | 1 |
Processor
| Cache | 42 MB |
| Processor Speed | 2.60 GHz |
| Processor Type | Xeon Gold |
| Processor Model | 6348 |
| Processor Core | Hexadeca-core (16 Core) |
| Processor Manufacturer | Intel |
| Number of Processors Supported | 2 |
| Number of Processors Installed | 1 |
| Processor Generation | 3rd Gen |
Price Trend
Current Price
AUD 113,515.05
