CATALYST 9200 24-PORT POE+. NETWORK ADVA
CATALYST 9200 24-PORT POE+. NETWORK ADVA
Product Overview
CATALYST 9200 24-PORT POE+. NETWORK ADVA
Extend Intent-Based Networking Everywhere
Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise - it is secure, always on, and IT simplified.
As foundational building blocks for the Cisco Digital Network Architecture, Catalyst 9200 Series switches help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.
Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology, Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.
With full PoE+ capability, power and fan redundancy, stacking bandwidth up to 160 Gbps, modular uplinks, Layer 3 feature support, and cold patching, Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access.
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Stack port provides an easy and hassle-free way to extend your office network
- Cascade to other network devices through the uplink port to expand your local area network
- Quickly and easily set up a wired network with 24 networking ports
Technical Specifications
Manageable | Yes |
Expansion Slot Type | Uplink Module |
Total Number of Expansion Slots | 1.0 |
Application/Usage | Business |
Data Center | |
Office |
Power Source | Power Supply |
Power Consumption | 600 W |
Redundant Power Supply Supported | Yes |
Weight (Approximate) | 5.50 kg |
Form Factor | Rack-mountable |
Height | 43.9 mm |
Width | 444.5 mm |
Depth | 350.5 mm |
Layer Supported | 3 |
Networking Standards | IEEE 802.3af |
IEEE 802.3at | |
IEEE 802.3u | |
IEEE 802.3x | |
IEEE 802.3z | |
IEEE 802.1D | |
IEEE 802.1p | |
IEEE 802.1Q | |
IEEE 802.1s | |
IEEE 802.1w | |
IEEE 802.1x | |
IEEE 802.3 | |
IEEE 802.3ab | |
IEEE 802.3ad |
Network Technology | 10/100/1000Base-T |
10GBase-X | |
Ethernet Technology | Gigabit Ethernet |
10 Gigabit Ethernet | |
Media Type Supported | Twisted Pair |
Optical Fiber |
Network (RJ-45) | Yes |
Modular | Yes |
Uplink Port | Yes |
Stack Port | Yes |
Total Number of Network Ports | 24 |
Port/Expansion Slot Details | 1 x Expansion Slot |
24 x Gigabit Ethernet PoE+ |
Product Type | Ethernet Switch |
Manufacturer Part Number | C920024PA |
Manufacturer Website Address | http://www.cisco.com/c/en_au |
Manufacturer | Cisco Systems, Inc |
Product Model | C9200-24P |
Product Name | Catalyst 9200 24-port PoE+ Switch, Network Advantage |
Product Line | Catalyst |
Product Series | 9200 |
Brand Name | Cisco |
