MERAKI (C9300-48T-M) C9300 48-PORT DATA ONLY, 350WAC PS, W/MERAKI
MERAKI (C9300-48T-M) C9300 48-PORT DATA ONLY, 350WAC PS, W/MERAKI
Product Overview
C9300 48-port data only 350wac PS w/MERAKI
Built to reimage connection, reinforce securityand redefine experience
Cisco®Catalyst®9300 Series switches are Cisco's lead stackable enterpriseaccessswitching platformand as part of the Catalyst 9000 family, are build to transform your network to handle a hybrid world where the workplace is anywhere, endpoints could be anything, and applications are hosted all over the place.
The Catalyst 9300 Series, including the new Catalyst 9300X models, continues to shape the future with continued innovation that helps you reimagine connections, reinforce security and redefine the experience for your hybrid workforce big and small.
The many industry'sfirst include:
- Up to 1TB of stacking bandwidth:With Stackwise-1T, Catalyst 9300switches are the industry's highest-density stacking bandwidth solution with the most flexible uplink architecture
- Flexible and dense uplink offeringswith 100G, 40G, 25G, Multigigabit, 10G, and 1G modular uplinks
- Mixed Stacking with Backward Compatibility-Stack your Catalyst 9300X fiber switches with Catalyst 9300and Catalyst 9300X Multigigabit switches, bringingstackable high-speed fiber to the access
- Highest Multigigabit Ports:With standalone and Stackwise-1T,Catalyst 9300X models enable 48 mGig ports in standalone and 448 mGig ports with an 8-member stack
- Highest 90W UPOE®+ Density:Enable your OT/IT needs with up to 36 ports of 90W UPOE+ for standalone or 288 ports of 90W UPOE+ with a 8-member stack.
- StackPower with Backward Compatibility:Enable power resiliency with higher power budgets in mixed Catalyst 9300and Catalyst 9300X stack.
- 100G IPsec in hardware:With the new 2.0Sec UADP ASIC, the Catalyst 9300X comes with 100G line rate IPsecto enable various options for new edge connectivity
- Secure Tunnel connectivity:With the new edge, the C9300X enables secureconnections to Secure Internet Gateway, Cloud Service Providers and Site to Site connectivity using IPsec tunnel with AES-256 Encryption and speeds up to 100G.
- Enhanced Application Hosting:With 2x capacity and additional RAM, QAT, and 2 x 10G AppGig Ports, multiple Cisco Signed performance savvy applications can be hosted on Catalyst 9300X
- ThousandEyes Enabled:End-to-end visualization of the path from campus/branch to clouds/DC with Cisco ThousandEyes Network and Application Synthetics (included with Cisco DNA Advantage licenses)
- Investment Protection:Catalyst 9300X redundant fansandpower supplies, data stack and StackPower cables are backward compatible with the Catalyst 9300
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Cascade to other network devices through the uplink port to expand your local area network
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 48 ports
- Quickly and easily set up a wired network with 48 networking ports
Technical Specifications
Manageable | Yes |
Network Technology | 10/100/1000Base-T |
Ethernet Technology | Gigabit Ethernet |
Media Type Supported | Twisted Pair |
Network (RJ-45) | Yes |
Modular | Yes |
Uplink Port | Yes |
Total Number of Network Ports | 48 |
Port/Expansion Slot Details | 48 x Gigabit Ethernet Network |
Application/Usage | VoIP Phone |
Wireless Access Point | |
IP Phone | |
Enterprise | |
Data Center | |
Business | |
Network |
Layer Supported | 3 |
Networking Standards | IEEE 802.1s |
IEEE 802.1w | |
IEEE 802.1x | |
IEEE 802.3 | |
IEEE 802.3ab | |
IEEE 802.3ad | |
IEEE 802.3af | |
IEEE 802.3an | |
IEEE 802.3at | |
IEEE 802.3bt | |
IEEE 802.3bz | |
IEEE 802.3u | |
IEEE 802.3x | |
IEEE 802.3z | |
IEEE 802.1ae | |
IEEE 802.1AVB | |
IEEE 802.1br | |
IEEE 802.1D | |
IEEE 802.1p | |
IEEE 802.1Q |
Weight (Approximate) | 7.45 kg |
Form Factor | Rack-mountable |
Height | 43.9 mm |
Width | 444.5 mm |
Depth | 408.9 mm |
Product Color | Grey |
Color Family | Grey |
Product Type | Ethernet Switch |
Manufacturer Part Number | C930048TM |
Manufacturer Website Address | http://www.cisco.com/c/en_au |
Manufacturer | Cisco Systems, Inc |
Product Model | C9300-48T |
Product Name | Catalyst C9300-48T-M Ethernet Switch |
Product Line | Catalyst |
Product Series | 9300 |
Brand Name | Cisco |
Input Voltage | 120 V AC |
230 V AC | |
Power Source | Power Supply |
AC | |
Frequency | 60 Hz |
50 Hz | |
Power Consumption | 350 W |
Number of Power Supplies Supported | 2 |
Number of Power Supplies Installed | 1 |
Redundant Power Supply Supported | Yes |
