CISCO BUSINESS 150AX WIFI 6 ACCESS POINT
CISCO BUSINESS 150AX WIFI 6 ACCESS POINT
Product Overview
Cisco Business 150AX WIFI 6 Access Point
The Cisco Business 150AX Access Point delivers industry-leading wireless performance with support for the latest Wi-Fi 6 standard, IEEE's 802.11ax (Figure 1). It also meets the growing flexibility of wireless networks by introducing mesh technology which enables scalable expansion of the network where network cabling may not exist-all while delivering a simple user experience, deployable with the Cisco Business Mobile app or the integrated WebUI.
The 150AX access point extends coverage and capacity to Wi-Fi clients such as smartphones, tablets, and high-performance laptops that have integrated Wi-Fi 6 capabilities, while being backwards compatible with the previous 802.11ac Wave 1 or Wave 2 standards.
- Gigabit Ethernet port for ultra-fast wired network speeds
- Up to 10x faster than standard Ethernet connectivity for your wired network
- Create a reliable wireless business network with this wireless access point that features a high-speed data transfer rate
- When connected to a compatible router or a network switch, this wireless access point lets you enjoy wireless internet connectivity throughout your home or office
Technical Specifications
| Communication Protocols | RADIUS |
| Wi-Fi Generation | Wi-Fi 6 |
| Network Band | Dual Band |
| Wireless Transmission Speed | 1.48 Gbit/s |
| Frequency Band | 2.40 GHz |
| 5 GHz | |
| Wireless LAN Standard | IEEE 802.11a/b/g/n/ac/ax/h/d/r/i |
| Bluetooth Standard | Bluetooth 5 |
| Encryption Standard | WPA3 |
| WPA2-ENT | |
| WPA | |
| PEAPv1 | |
| PEAPv0 | |
| EAP-TTLS | |
| EAP-TLS | |
| EAP-SIM | |
| EAP-GTC | |
| EAP-FAST | |
| AES | |
| WPA2 | |
| Data Encryption | Yes |
| MIMO Technology | Yes |
| Beamforming Technology | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| Package Contents |
|
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Weight (Approximate) | 330 g |
| Form Factor | Ceiling Mountable |
| Wall Mountable | |
| Height | 39.9 mm |
| Width | 150.4 mm |
| Depth | 150.4 mm |
| Antenna Form Factor | Internal |
| Product Type | Wireless Access Point |
| Manufacturer Part Number | CBW150AXZAU |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 150AX |
| Product Name | Business 150AX Access Point |
| Product Line | Business |
| Product Series | 100 |
| Brand Name | Cisco |
