Product Overview

CS6080-HC WHITE CORDLESS FIPS PRESENTATION CRADL w LANYARD KIT

Ultra-versatile healthcare scanner with a first-of-its-kind convertible design

Do you need a cordless scanner at the point of care and a corded hands-free scanner in the pharmacy and lab? What if you didn't have to deploy different scanners for different tasks? Introducing the CS60-HC Series Healthcare Companion Scanner, featuring a groundbreaking design that easily converts between corded and cordless operation, handheld and hands-free, as your needs change. As a cordless scanner, the CS60-HC is ultra-portable and pocketable to meet any nurse-carry workflow and offers the latest mobile technology including contactless charging. As a corded scanner, the CS60-HC provides compact scanning for the pharmacy counter, lab station and more. Whether you purchase a corded or cordless model up front, you can change modes at any time for superior investment protection. You get Zebra's industry-leading scanning performance, easier data entry between multiple host applications and seamless disinfectant-ready plastics. And our unique DataCapture DNA and industry-preferred management tools make it easier than ever to integrate, deploy and manage your scanners.

Proven scanning performance you can trust

With a high-resolution megapixel sensor and Zebra's exclusive PRZM Intelligent Imaging technology, the CS60-HC easily and accurately captures the many kinds of barcodes commonly used in hospitals including barcodes on patient wristbands, medication vials, IV bags and specimen trays. When you choose the CS60-HC, you get Zebra's world-renowned quality and reliability

Effortless multi-tasking with a second programmable button

A second programmable button can be used to instantly toggle between two host applications, such as Electronic Medical Record (EMR) and blood collection applications. With a quick press of the button, clinicians can send data to the right application in the proper format and order.

Purpose-built housing helps offer maximum protection against the spread of bacteria

Special plastics and IP65 sealing allow for safe wipe-downs with the widest selection of aggressive disinfectants used in today's hospitals. And with a monocoque design, inductive sensing touch buttons and contactless charging, the scanner's crevice-free surface helps eliminate places where germs can hide.

Safe LED aimer can be used throughout the hospital

Thanks to a highly visible and safe LED aimer, the CS60-HC can be used in the NICU, labor and delivery and mother-baby units where the use of laser aimers is not advised. And the green aimer reduces the likelihood of triggering PTSD episodes.

  • Bluetooth technology - Allows compatibility with most of your smart devices
  • Perfect for applications that require direct association with a workstation or a notebook
  • Laser-free design provides high-performance scanning without the risk of eye injury

Technical Specifications

Interfaces/Ports
Host InterfaceUSB
Technical Information
Barcode Symbology Supported

    1D:

    • Base 32 (Italian Pharma)
    • Codabar/NW7
    • Code 11
    • Code 39
    • Code 93
    • Code 128
    • GS1 DataBar
    • I 2 of 5
    • Korean 3 of 5
    • MSI Plessey
    • UPC/EAN

    2D:

    • Aztec
    • Composite Codes
    • DataMatrix
    • Dotted DataMatrix
    • Dotcode
    • Han Xin
    • MaxiCode
    • PDF417
    • Micro PDF417
    • Postal Codes
    • QR Code
    • Micro QR
    • TLC-39
    • SecurPharm
Connectivity TechnologyCable
FeaturesBeep
Checkpoint EAS
Data Formatter
Vibration
NFC Reader
Diagnostic Reporting
Light SourceLED
Drop Specification

Designed to withstand multiple drops at 5.0 ft./1.5 m
to concrete

Image Sensor TypeImager
Illumination TypeLED
Stand IncludedYes
Illumination ColorWhite
Cable Type IncludedUSB
Scanning Capability2D
1D
Field of View (Horizontal)45°
Field of View (Vertical)34°
Reading Angle (Skew)60°
Reading Angle (Pitch)60°
Reading Angle (Roll)360°
Motion Tolerance508 mm/s
Maximum Ambient Light108000 lux
Minimum Print Contrast20%
Maximum Element Resolution (Code 39)0.13 mm
Minimum Element Resolution (DataMatrix)0.25 mm
Minimum Element Resolution (PDF417)0.17 mm
Air Electrostatic Discharge (+/-)15kV
Image Sensor Resolution1280 x 960
Network & Communication
BluetoothYes
Power Description
Input Current400 mA
Standby Current90 mA
Battery Information
Battery ChemistryLithium Ion (Li-Ion)
Battery Capacity735 mAh
Battery IncludedYes
General Information
Product TypeBarcode Scanner Kit
Manufacturer Part NumberCS6080HCB0000TP1W
Manufacturer Website Addresshttp://www.zebra.com/ap/en.html
ManufacturerZebra Technologies Corporation
Product NameCS60-HC Barcode Scanner Kit
Product SeriesCS60-HC
Brand NameZebra
Physical Characteristics
Weight (Approximate)87.9 g
Form FactorHandheld
Height22.9 mm
Width45.7 mm
Depth109.2 mm
Product ColorHealthcare White
Color FamilyWhite
Miscellaneous
Application/UsageHealthcare
Specimen Collection
Pharmacy
Inventory
Package Contents
  • CS60-HC Barcode Scanner Kit
  • Presentation cradle
  • Spare battery
  • 4-slot scanner ShareCradle
  • 4-slot battery ShareCradle
  • Lanyard
Environmentally FriendlyYes
Ingress Protection (IP) RatingIP65
Environmental ComplianceRegistration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Restriction of Hazardous Substances (RoHS)
