Product Overview

DuraSled DS800 Linear Barcode Sled Reader f/iPhone 15 (6 units)+6 Bay Charger Bundle EMEA

The XtremeScan Mag XG640 delivers exceptional scanning performance. It is designed for BYOD (Bring Your Own Device) operations and easily integrates with any mobile device, providing the optimal solution to enhance efficiency and convenience in mobile workforces. Featuring a secure magnetic attachment system, workers can easily attach and detach their personal mobile devices to the scanner throughout the workday. This versatility empowers users to utilize their smartphones for tasks such as navigation, photos, and communication while adding high-performance barcode scanning when needed. The XG640's innovative BYOD design and rugged durability make it ideal for modern delivery operations, ensuring that tasks are handled efficiently without the need for multiple devices.

Featuring a comfortable pistol grip handle and fast, omnidirectional 1D/2D barcode scanning, the XG640 provides a convenient "point and shoot" approach for effortless data capture during work shifts. It boasts extended battery life for continuous operation, military-grade durability to withstand drops and harsh conditions, and a user-friendly interface with intuitive LED indicators and a multi-function trigger button to simplify scanning tasks.

With Bluetooth connectivity and a strong metal plate attachment system, the XG640 ensures optimal compatibility with any chosen mobile device and ensures reliable integration with iOS and Android business applications.

  • Bluetooth technology - Allows compatibility with most of your smart devices
  • Increase productivity and performance by excluding the cable
  • Wireless connectivity gives you the adaptability to transmit barcode data to your smart devices
  • Laser-free design provides high-performance scanning without the risk of eye injury
  • LED aimer is a perfect choice for patient-facing applications

Technical Specifications

Network & Communication
BluetoothYes
Physical Characteristics
DurabilityDust Resistant
Water Resistant
Form FactorHandheld
RuggedYes
Battery Information
Battery ChemistryLithium Polymer (Li-Polymer)
Battery Capacity700 mAh
Battery IncludedYes
Maximum Battery Run Time25 Hour
Maximum Battery Recharge Time8 Hour
Battery Weight12.5 g
Technical Information
Barcode Symbology Supported

    1D:

    • Bookland EAN, Chinese 2 of 5, Codabar, Code 11, Code 39, Code 93, Code 128, Composite CC-A/B, Composite CC-C, Composite TLC, Discrete 2 of 5, EAN-13/JAN, EAN8/JAN, GS1 Databar, GS1 Databar Expanded, GS1 Databar Limited, GS1-128, Interleaved 2 of 5, ISBT 128, ISSN EAN, Matrix 2 of 5, MSI, UPC/EAN/JAN, UPC A, UPC EO

    2D:

    • Aztec, Data Matrix, DotCode, GS1 Data Matrix, GS1 QR Code, Maxicode, Micro PDF417, MicroQR, PDF417, QR Code

    Postal Codes:

    • Australia Post, Han Xin, Japan Postal, KIX Code, Maxicode, Netherlands, UPU FICS Posta, US Planet, US Postnet, USPS 4CB/One Code/Intelligent Mail

    OCR Typeface:

    • OCR-A, OCR-B, MICR (E13B), US currency serial number
Connectivity TechnologyWireless
FeaturesScan Button
Notification LED
Scanning Distance495.30 mm
Light SourceLED
Drop Specification

    Standard:

    • 10 ft. (3.1m) drop at room temperature per MIL-STD-810G
    • 8 ft. (2.4m) drop to concrete across temperature per MIL-STD-810G

    Freezer:

    • 7 ft. (2.1m) drop to concrete across temperature per MIL-STD-810G.
Scan PatternOmni-directional
Image Sensor TypeImager
Scan ModeTrigger
Scanning Capability2D
1D
Field of View (Horizontal)45°
Field of View (Vertical)34°
Maximum Ambient Light86000 lux
Minimum Print Contrast25%
Minimum Element Resolution (Code 39)0.13 mm
Minimum Element Resolution (DataMatrix)0.25 mm
Minimum Element Resolution (PDF417)0.17 mm
Image Sensor Resolution1280 x 960
General Information
Product TypeBarcode Scanner
Manufacturer Part NumberCX4274-3386
Manufacturer Website Addresshttp://www.socketmobile.com
ManufacturerSocket Mobile, Inc
Product ModelXG640
Product NameXtremeScan XG640 Barcode Scanner
Product LineXtremeScan
Brand NameSocket Mobile
Miscellaneous
Application/UsageCommercial Service
Asset Tracking
Logistics
Manufacturing
Inventory
Warehouse
Transportation
Platform SupportedPC
Mac
Linux
iOS
Android
Ingress Protection (IP) RatingIP67

Price Trend

Current Price
AUD 1,294.03
