Product Overview

DS3678-HP RUGGED FIPS Vib Keypad Display STD Cradle NO LINE CORD KIT USB CBL

Unstoppable performance with the versatility of a keypad and color display Warehouses, retailers and manufacturers face unrelenting pressure to deliver more - and to do it faster and more accurately.

Rise to meet the challenge with the DS3600-KD Ultra-Rugged Scanner with Keypad and Color Display. Built for your toughest environments, the DS3600-KD is virtually indestructible, including an enhanced 10 ft./3 m drop spec to concrete. The scanner reads barcodes in any condition, whether they're in hand or as far as 7 ft./2.1 m away. Workers can key in data, such as adding quantity and location, with the ergonomic keypad and color display. Pre-built applications offer the same 'point and shoot' simplicity of a scanner and enable workers to complete picking, putaway and inventory tasks with amazing efficiency and accuracy. And DataCapture DNA, Zebra's exclusive software ecosystem, takes scanner performance far beyond the basics - simplifying every stage of the scanning experience over the life of your device

Ultra-rugged - the most indestructible design in its class

Zebra ultra-rugged scanners earned their name for a reason - you won't find a tougher family of scanners. The DS3600-KD has the highest drop, tumble and sealing specifications in its class. It can survive 10 ft./3 m drops to concrete and 7,500 tumbles. With dual IP65/IP68 sealing, the DS3600-KD is dust proof, can handle the force of jetting water and be fully submerged in water. Built to withstand extreme heat, cold and humidity, the DS3600-KD can be used anywhere - indoor, outdoor and even in the freezer.

Scan it all - at astonishing speeds

Workers can capture virtually any 1D or 2D barcode as fast as they can pull the trigger, from as far as 7 ft./2.1 m away. Powered by Zebra's exclusive PRZM Intelligent Imaging technology and the highest sensor resolution in its class, the DS3600-KD instantly captures the most problematic barcodes - including barcodes that are dirty, damaged, poorly printed and under shrinkwrap.

The first ultra-rugged scanner with a color display and keypad

Make picking, inventory and point of sale tasks more efficient with the keypad and color display. The ergonomic backlit keypad is well designed for one-handed operation. The color display provides a more intuitive, modern experience and the display brightness automatically adjusts for easy viewing in any lighting condition

Pre-built applications ready to use right out of the box

The DS3600-KD takes the complexity out of app development and integration. Start using our pre-built applications on day one - including the ability to add quantity and/or location data to any scanned barcode, confirm that the contents inside a container match the outer label, and even add location data during inventory counts while roaming away from the host. There's virtually no learning curve for workers - if they can use a scanner, they can use the pre-built applications. And the ability for future customization can meet specific application needs.

Capture OCR, photos and documents

The DS3600-KD makes it easy to take high quality photos for documentation. With Image Viewer, workers can quickly check an image before sending it to the host. Zebra's Intelligent Document Capture automatically de-skews and brightens document images. And support for multiple OCR fonts enables fast, easy data transfer.

  • Bluetooth technology - Allows compatibility with most of your smart devices
  • With Bluetooth technology, you can scan barcodes and then transmit data from the base
  • Increases productivity by giving the opportunity to wander, without the tangle of cables
  • Wireless connectivity gives you the adaptability to transmit barcode data to your smart devices

Technical Specifications

Interfaces/Ports
Host InterfaceUSB
Network & Communication
BluetoothYes
Power Description
Power Supply IncludedYes
Battery Information
Battery ChemistryLithium Ion (Li-Ion)
Battery Capacity3100 mAh
General Information
Product TypeBarcode Scanner Kit
Manufacturer Part NumberDS3678-HP3U42A2SKW
Manufacturer Website Addresshttp://www.zebra.com/ap/en.html
ManufacturerZebra Technologies Corporation
Product ModelDS3678-KD
Product NameDS3600-KD DS3678-KD Barcode Scanner Kit
Product SeriesDS3600-KD
Brand NameZebra
Technical Information
Barcode Symbology Supported

    1D:

    • Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma)

    2D:

    • PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes

    OCR:

    • OCR-A/B, MICR-E13B, US Currency Serial Number

    IUID:

    • Support Supports IUID parsing, the ability to read and separate IUID fields per application requirements
Number of Keys19
Connectivity TechnologyWireless
FeaturesVibration
Notification LED
Ergonomic Design
Data Formatter
Beep
Scanning Distance2.03 m
Drop Specification
    • Withstands multiple 10.0 ft./3.0 m drops to concrete at room temperature
    • Withstands multiple 8.0 ft./2.4 m drops to concrete at -4° F to 122° F/-20° C to 50° C
Image Sensor TypeImager
Illumination TypeLED
Keypad TypeAlphanumeric
Scan ModeTrigger
Illumination ColorWhite
Cable Type IncludedUSB
Scanning Capability2D
1D
Field of View (Horizontal)31°
Field of View (Vertical)23°
Reading Angle (Skew)60°
Reading Angle (Pitch)60°
Reading Angle (Roll)360°
Maximum Ambient Light108000 lux
Minimum Print Contrast15%
Minimum Element Resolution (DataMatrix)0.19 mm
Maximum Element Resolution (DataMatrix)0.25 mm
Air Electrostatic Discharge (+/-)25kV
Contact Electrostatic Discharge (+/-)10kV
Image Sensor Resolution1280 x 960
Physical Characteristics
DurabilityWater Resistant
Water Proof
Dust Proof
Form FactorHandheld
Height190.5 mm
Width78.7 mm
Depth142.2 mm
Product ColorIndustrial Green
Green
Black
Color FamilyDual Colour
RuggedYes
Miscellaneous
Application/UsageDistribution
Industrial
Asset Tracking
Warehouse
Self-checkout
Retail
Picking
Inventory
Manufacturing
Outdoor
Packing
Package Contents
  • 1 x DS3600-KD DS3678-KD Barcode Scanner
  • 1 x Cable (USB)
  • 1 x Power supply unit
  • 1 x Charging/transmitter cradle
Environmentally FriendlyYes
Ingress Protection (IP) RatingIP68
IP67
IP65
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
