EPDU MI 2U (309 32A 1P)C13x12:C19x4
EPDU MI 2U (309 32A 1P)C13x12:C19x4
Product Overview
Eaton ePDU EMIH06 PDU - IEC 60309 32A - 12 x IEC 60320 C13, 4 x IEC 60320 C19 - 32 A - 230 V AC Input - 7 kW - 1U/2U Network (RJ-45) - Horizontal/Vertical
Models available in 0U, 1U and 2UePDU G3 Metered Input models allow metering to the branch and phase level for effective load balancing, with no switching. Models include IEC Class 1 (±1%) billing grade accuracy, an advanced hot-swap meter with LCD pixel display showing V, W, A and kWh, and the ability to daisy chain 8 ePDUs to share the same network connection and IP address.
Technical Specifications
Interfaces/Ports
| Network (RJ-45) | Yes |
Miscellaneous
| Environmentally Friendly | Yes |
Power Description
| Input Voltage | 230 V AC |
| Input Current | 32 A |
| Power Rating (Watt) | 7 kW |
General Information
| Product Type | PDU |
| Manufacturer Part Number | EMIH06 |
| Manufacturer Website Address | http://www.eatoncorp.com.au |
| Manufacturer | Eaton Corporation |
| Product Model | EMIH06 |
| Product Name | ePDU Metered EMIH06 16-Outlet PDU |
| Product Line | ePDU |
| Product Series | Metered |
| Brand Name | Eaton |
Physical Characteristics
| Rack Height | 1U/2U |
| Height | 127 mm |
| Width | 88.9 mm |
| Depth | 482.6 mm |
| Mounting Orientation | Horizontal/Vertical |
Technical Information
| Plug/Connector Type | IEC 60309 32A |
| Receptacle Type | IEC 60320 C19 |
| IEC 60320 C13 | |
| Receptacle Detail | 4 x IEC 60320 C19 |
| 12 x IEC 60320 C13 | |
| Plug/Connector Detail | 1 x IEC 60309 32A |
Price Trend
Current Price
AUD 2,004.00
