Gigabit Fiber Media Converter LC 40 km
Gigabit Fiber Media Converter LC 40 km
Product Overview
StarTech.com Transceiver/Media Converter - TAA Compliant - 2 Port(s) - 1 x Network (RJ-45) - Duplex LC Port - Twisted Pair, Optical Fiber - Single-mode - Gigabit Ethernet - 1000Base-T, 1000Base-SX/LX - 40 km - AC Adapter - Desktop, Rack-mountable
The ET1000S40LC2 1000 Mbps Gigabit Single-Mode Fiber Media Converter (LC, 40 km) enables you to extend a Gigabit Ethernet network over single-mode fiber, at distances up to 40km (25 miles).
A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-LX/SX) fiber backbone, the GbE to SM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, the Ethernet to LC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Technical Specifications
| Network Technology | 1000Base-SX/LX |
| 1000Base-T |
| Compatibility | ETCHS2U Rackmount Chassis |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
| Input Voltage | 12 V DC |
| Power Source | AC Adapter |
| Power Consumption | 4 W |
| Plug/Connector Type | Type M |
| USB | No |
| DVI | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Parallel Port | No |
| Management Port | No |
| Digital Audio | No |
| Number of LC Ports | 1 |
| Digital Audio/Video | No |
| Total Number of Ports | 2 |
| LC Port Type | Duplex |
| Maximum Distance Supported | 40 km |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Fiber Mode Supported | Single-mode |
| Fiber Optic Wavelength | 1310 nm |
| Weight (Approximate) | 408.2 g |
| Height | 22.9 mm |
| Width | 86.4 mm |
| Depth | 154.9 mm |
| Product Color | Black |
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | ET1000S40LC2 |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | 1000 Mbps Gigabit Single Mode Fiber Media Converter LC 40 km |
| Brand Name | StarTech.com |
