Gigabit Ethernet MM Fiber Converter SC
Gigabit Ethernet MM Fiber Converter SC
Product Overview
StarTech.com Transceiver/Media Converter - TAA Compliant - 2 Port(s) - 1 x Network (RJ-45) - 1 x SC - Duplex SC Port - Twisted Pair, Optical Fiber - Multi-mode - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-SX/LX - 550 m - AC Adapter - Rack-mountable, Desktop
The ET91000SC2 1000 Mbps Gigabit Multimode Fiber Media Converter (SC, 550m) lets you extend a Gigabit Ethernet network over multimode fiber, at distances up to 550m (1804 ft).A cost-effective solution for connecting a Gigabit Ethernet (1000Base-T) network to remote network segments over a (1000Base-SX) fiber backbone, the GbE to MM fiber converter supports full Gigabit speeds for ideal network performance and scalability. Designed to offer a durable and convenient Ethernet to fiber solution, this Ethernet to SC Fiber converter features an all-steel chassis, and a simple plug-and-play installation with minimal configuration required.
For added versatility, the fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Technical Specifications
Network & Communication
| Network Technology | 1000Base-SX/LX |
| 10/100/1000Base-T |
Miscellaneous
| Compatibility | ETCHS2U Rackmount Chassis |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| TAA Compliant | Yes |
Power Description
| Input Voltage | 12 V DC |
| Power Source | AC Adapter |
| Power Consumption | 4 W |
| Plug/Connector Type | Type M |
Interfaces/Ports
| USB | No |
| DVI | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Parallel Port | No |
| Management Port | No |
| Digital Audio | No |
| Number of SC Ports | 1 |
| Digital Audio/Video | No |
| Total Number of Ports | 2 |
Media & Performance
| Maximum Distance Supported | 550 m |
| Media Type Supported | Optical Fiber |
| Twisted Pair | |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Wavelength | 850 nm |
Physical Characteristics
| Weight (Approximate) | 394.1 g |
| Height | 25.4 mm |
| Width | 88.9 mm |
| Depth | 149.9 mm |
| Product Color | Black |
General Information
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | ET91000SC2 |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 |
| Manufacturer | StarTech.com |
| Product Name | Gigabit Ethernet Multi Mode Fiber Media Converter SC 550m - 1000 Mbps |
| Brand Name | StarTech.com |
Price Trend
Current Price
AUD 450.99
