Product Overview
OUTDOOR WIRELESS FORTIAP - TRI RADIO (1X 802.11B/G/N/AX 4X4 RADIO 1 X 802.11A/N/AC/AX 4X4 RADIO AND 1X 802.11 A/B/G/N/AC WAVE 2 2X2) 1X 10/100/1000/2500 BASE-T RJ45 1X 10/100/1000 BASE-T RJ45 BT/BLE +
This enterprise class 802.11ax outdoor AP provides three radios. As a top-of-the-line Wi-Fi 6 access point it provides OFDMA, a 2.5 Gigabit Ethernet port, plus an additional 1 Gbps Ethernet port with PoE out. The AP can provide 24/7 scanning across both bands while still providing access on both the 2.4 and 5 GHz bands. The integrated BLE radio can be used for beacons and locationing applications.
- Gigabit Ethernet port for ultra-fast wired network speeds
- Up to 10x faster than standard Ethernet connectivity for your wired network
- Its management capability provides efficient control over setup and configuration of your network
- Provide your business with a wireless solution that ensures a speedy and steady data transfer rate
Technical Specifications
| Power Consumption | 25 W |
| Ethernet Technology | Gigabit Ethernet |
| 2.5 Gigabit Ethernet | |
| USB | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Management Port | Yes |
| PoE PD Port | Yes |
| Wireless Transmission Speed | 3.47 Gbit/s |
| Frequency Band | 2.40 GHz |
| 5 GHz | |
| Wireless LAN Standard | 802.11ax |
| Encryption Standard | WEP |
| WPA3 | |
| WPA-PSK | |
| WPA2 | |
| WPA2-PSK | |
| WPA3-PSK | |
| WPA | |
| Data Encryption | Yes |
| MIMO Technology | Yes |
| Indoor/Outdoor | Outdoor |
| Ingress Protection (IP) Rating | IP67 |
| Product Type | Wireless Access Point |
| Manufacturer Part Number | FAP-432F-N |
| Manufacturer Website Address | http://www.fortinet.com |
| Manufacturer | Fortinet, Inc |
| Product Model | FAP-432F |
| Product Name | 4x4 Outdoor Tri-radio 11ax AP, External Antennas |
| Product Line | FortiAP |
| Brand Name | Fortinet |
| Weight (Approximate) | 2.32 kg |
| Form Factor | Pole-mountable |
| Ceiling Mountable | |
| Desktop | |
| Rail-mountable | |
| Wall Mountable | |
| Height | 60.5 mm |
| Width | 209 mm |
| Depth | 209 mm |
| Antenna Form Factor | External |
