FORTICAM-FE120B 12 MEGAPIXEL PANORAMIC I
FORTICAM-FE120B 12 MEGAPIXEL PANORAMIC I
Product Overview
Fortinet FortiCamera FCM-FE120B 12 Megapixel Indoor/Outdoor Network Camera - Fisheye - 20 m Infrared Night Vision - H.265, H.264, MJPEG, H.265 (HEVC) - 2944 x 2944 - 1.22 mm Fixed Lens - 30 fps - CMOS - Gigabit Ethernet - Ceiling Mount, Wall Mount, Table Mount, Pole Mount, Junction Box Mount - IK10 - IP66 - Vandal Proof
This 12 mega-pixel fisheye camera delivers superior security and video performance where excellent overview is demanded. When ceiling mounted, the FortiCamera FE120B camera provides a 360-degree field of view, giving you wide coverage with no blind spot. Its compact design is packed with a rich feature set, including IP66 weather rating, built-in audio mic and IR illuminators. Low light and complicated light situations against windows are handled with the high sensitivity CMOS sensor and Shutter WDR (>120dB). This powerhouse delivers worry free installation with dynamic panoramic coverage to ensure the safety of your environment.
- CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
- Network camera - Helps achieve high-quality video results
- Up to 2944 x 2944 resolution for surveillance in real-time
- Provides night vision of objects at a distance of up to 20 m
Technical Specifications
| Network (RJ-45) | Yes |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | -55°C |
| Maximum Focal Length | 1.22 mm |
| Lens Included | Yes |
| Night Vision | Yes |
| Night Vision Distance | 20 m |
| Night Vision Type | Infrared |
| Image Sensor Size | 1/2.3" |
| Image Sensor Type | CMOS |
| Effective Camera Resolution | 12 Megapixel |
| Field of View | 360 |
| Weight (Approximate) | 703.1 g |
| Durability | Vandal Proof |
| Form Factor | Fisheye |
| Length | 150 mm |
| Mount Type | Wall Mount |
| Pole Mount | |
| Table Mount | |
| Ceiling Mount | |
| Junction Box Mount | |
| Height | 68 mm |
| Width | 150 mm |
| Protocols | RTSP |
| Connectivity Technology | Wired |
| Ethernet Technology | Gigabit Ethernet |
| Remote Management | Yes |
| Features | Wide Dynamic Range |
| Built-in Microphone | |
| 3D Digital Noise Reduction | |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| Video Formats | H.265 |
| H.265 (HEVC) | |
| MJPEG | |
| H.264 | |
| Maximum Video Resolution | 2944 x 2944 |
| Maximum Frame Rate | 30 fps |
| Product Type | Network Camera |
| Manufacturer Part Number | FCMFE120B |
| Manufacturer Website Address | http://www.fortinet.com |
| Manufacturer | Fortinet, Inc |
| Product Model | FCM-FE120B |
| Product Name | FortiCam FE120B Fisheye Camera |
| Product Line | FortiCamera |
| Brand Name | Fortinet |
