FortiGate-1001F
FortiGate-1001F
Product Overview
Fortinet FortiGate FG-1001F Network Security/Firewall Appliance - 8 Port - 100GBase-X - 100 Gigabit Ethernet, 10GBase-T - 19 Gbit/s Firewall Throughput - SHA-256, AES (256-bit), RSA - 100000 VPN - 8 x RJ-45 - 26.0 Total Expansion Slots - 2U - Rack-mountable
High Performance with Flexibility
The FortiGate 1000F Series enables organizations to build security-driven networks that can weave security deep into their datacenter and across their hybrid IT architecture to protect any edge at any scale.
Powered by a rich set of AI/ML-based FortiGuard Services and an integrated security fabric platform, the FortiGate 1000F Series delivers coordinated, automated, end-to-end threat protection across all use cases.
The industry's first integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution, FortiGate 1000F automatically controls, verifies, and facilitates user access to applications delivering consistent convergence with a seamless user experience.
- Gartner Magic Quadrant Leader for both Network Firewalls and SD-WAN.
- Security-Driven Networking FortiOS delivers converged networking and security
- Unparalleled Performance with Fortinet's patented / SPU / vSPU processors.
- Enterprise Security with consolidated AI / ML-powered FortiGuard Services.
- Hyperscale Security to secure any edge at any scale.
Technical Specifications
| Manageable | Yes |
| VPN Throughput | 6.88 GB/s |
| Frequency | 60 Hz |
| 50 Hz |
| USB | Yes |
| Number of Network (RJ-45) Ports | 8 |
| Total Number of Ports | 8 |
| Application/Usage | Data Center |
| Enterprise | |
| Package Contents |
|
| Firewall Protection Supported | URL Filtering |
| Web Content Filtering | |
| Web Protection | |
| Zero Day Event | |
| SSL Inspection | |
| Anti-spam | |
| Malware Protection | |
| Application Control | |
| Antivirus | |
| Encryption Standard | AES (256-bit) |
| RSA | |
| SHA-256 | |
| Firewall Throughput | 19 Gbit/s |
| Number of VPN Supported | 100000 |
| Network Standard | 100GBase-X |
| 10GBase-T | |
| Ethernet Technology | 100 Gigabit Ethernet |
| Weight (Approximate) | 10.30 kg |
| Height | 88.9 mm |
| Width | 443 mm |
| Depth | 447.8 mm |
| Expansion Slot Type | SFP28 |
| SFP+ | |
| SFP | |
| QSFP28 | |
| QSFP+ | |
| Number of SFP+ Slots | 16 |
| Total Number of Expansion Slots | 26.0 |
| Product Type | Network Security/Firewall Appliance |
| Manufacturer Part Number | FG-1001F |
| Manufacturer Website Address | http://www.fortinet.com |
| Manufacturer | Fortinet, Inc |
| Product Model | FG-1001F |
| Product Name | FortiGate FG-1001F Network Security/Firewall Appliance |
| Product Line | FortiGate |
| Product Series | 1000F |
| Brand Name | Fortinet |
