FortiSwitch FS-248E-POE
FortiSwitch FS-248E-POE
Product Overview
Fortinet FortiSwitch FS-248E-POE 48 Ports Manageable Ethernet Switch - Gigabit Ethernet - 1000Base-T, 1000Base-X - 3 Layer Supported - Modular - 4 SFP Slots - 51.60 W Power Consumption - Optical Fiber, Twisted Pair - 1U High - Rack-mountable
The FortiSwitch Secure Access Family delivers outstanding security, performance and manageability. Secure, Simple, and Scalable, FortiSwitch is the right choice for threat conscious businesses of all sizes.Tightly integrated into the Fortinet Security Fabric via FortiLink, FortiSwitch can be managed directly from the familiar FortiGate interface. This single pane of glass management provides complete visibility and control of users and devices on the network regardless of how they connect. This makes the FortiSwitch ideal for SD-Branch deployments with applications that range from desktop to data center aggregation, enabling businesses to converge their security and network access.
Security Fabric Integration through FortiLink
FortiLink is an innovative proprietary management protocol that allows our FortiGate Next Generation Firewall to seamlessly manage any FortiSwitch. FortiLink enables the FortiSwitch to become a logical extension of the FortiGate, integrating it directly into the Fortinet Security Fabric. This management option reduces complexity and decreases management cost as network security and access layer functions are enabled and managed through a single console. FortiLink integration enables centralized policy management, including role-based access and control, making it easy to implement and manage. This control and manageability make FortiSwitch ideal for SD-Branch deployments.
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports optical fibre cable to span longer distances and provided high data transmission rates between servers and network components
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 48 ports
Technical Specifications
Management & Protocols
Manageable | Yes |
Network & Communication
Layer Supported | 3 |
Power Description
Power Source | Power Supply |
Power Consumption | 51.60 W |
I/O Expansions
Expansion Slot Type | SFP (mini-GBIC) |
Number of SFP Slots | 4 |
Total Number of Expansion Slots | 4.0 |
Interfaces/Ports
Modular | Yes |
Total Number of Network Ports | 48 |
Port/Expansion Slot Details | 4 x Gigabit Ethernet Expansion Slot |
24 x Gigabit Ethernet PoE | |
24 x Gigabit Ethernet Network |
Media & Performance
Network Technology | 1000Base-X |
1000Base-T | |
Ethernet Technology | Gigabit Ethernet |
Media Type Supported | Optical Fiber |
Twisted Pair |
Physical Characteristics
Weight (Approximate) | 5.50 kg |
Form Factor | Rack-mountable |
Height | 44 mm |
Width | 440 mm |
Depth | 410 mm |
Compatible Rack Unit | 1U |
General Information
Product Type | Ethernet Switch |
Manufacturer Part Number | FS248EPOE |
Manufacturer Website Address | http://www.fortinet.com |
Manufacturer | Fortinet, Inc |
Product Model | FS-248E-POE |
Product Name | FortiSwitch FS-248E-POE Ethernet Switch |
Product Line | FortiSwitch |
Brand Name | Fortinet |
Price Trend
Current Price
AUD 4,175.00
