GBE
Product Overview
| Mechanical | |
|---|---|
| Dimensions | Ø140 x 44 mm (Ø5.5 x 1.7") |
| Weight | 376 g (13.3 oz) |
| Enclosure material | UV-resistant polycarbonate |
| Hardware | |
| Processor | Quad-core ARM® Cortex® A7 |
| Memory | 256 MB DDR3 |
| Networking interface | (1) GbE RJ45 port |
| RF connections | Internal |
| Power method | Passive PoE 2-pairs (4, 5+; 7, 8-) |
| Power supply | 24V DC, 0.5A gigabit PoE adapter (Included) |
| Voltage range | 22—27V DC |
| Max. power consumption | 11W |
| ESD/EMP protection | Air/contact: ± 24kV |
| LEDs | Power/Ethernet/5G/60G |
| Ambient operating temperature | -40 to 60° C (-40 to 140° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | FCC, IC, CE |
| Software | |
| Operating mode | PtP |
| Ubiquiti specific features | Integrated 60 GHz and 5 GHz radios, discovery protocol |
| Security | WPA2 AES only |
| Services | UISP, ping watchdog, web server, SSH server, NTP client, system log, device discovery |
| Tools | Antenna alignment tool, discovery utility, traceroute, speed test |
| Management interface | UISP application (web/mobile) |
| Minimum software requirements | Any modern web browser/iOS™ or Android™ based smartphone |
Technical Specifications
| Mechanical | |
|---|---|
| Dimensions | Ø140 x 44 mm (Ø5.5 x 1.7") |
| Weight | 376 g (13.3 oz) |
| Enclosure material | UV-resistant polycarbonate |
| Hardware | |
| Processor | Quad-core ARM® Cortex® A7 |
| Memory | 256 MB DDR3 |
| Networking interface | (1) GbE RJ45 port |
| RF connections | Internal |
| Power method | Passive PoE 2-pairs (4, 5+; 7, 8-) |
| Power supply | 24V DC, 0.5A gigabit PoE adapter (Included) |
| Voltage range | 22—27V DC |
| Max. power consumption | 11W |
| ESD/EMP protection | Air/contact: ± 24kV |
| LEDs | Power/Ethernet/5G/60G |
| Ambient operating temperature | -40 to 60° C (-40 to 140° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | FCC, IC, CE |
| Software | |
| Operating mode | PtP |
| Ubiquiti specific features | Integrated 60 GHz and 5 GHz radios, discovery protocol |
| Security | WPA2 AES only |
| Services | UISP, ping watchdog, web server, SSH server, NTP client, system log, device discovery |
| Tools | Antenna alignment tool, discovery utility, traceroute, speed test |
| Management interface | UISP application (web/mobile) |
| Minimum software requirements | Any modern web browser/iOS™ or Android™ based smartphone |
