1000 Base-ZX Single Mode RuggedSFP
1000 Base-ZX Single Mode RuggedSFP
Product Overview
1000 Base-ZX Single Mode RuggedSFP
The 1000BASE-ZX SFP operates on standard single-mode fiber-optic link spans of up to approximately 70 km in length. The SFP provides an optical link budget of 23 dB, but the precise link span length depends on multiple factors such as fiber quality, number of splices, and connectors.
When shorter distances of single-mode fiber (SMF) are used, it might be necessary to insert an inline optical attenuator in the link to avoid overloading the receiver. A 10-dB inline optical attenuator should be inserted between the fiber-optic cable plant and the receiving port on the SFP at each end of the link whenever the fiber-optic cable span loss is less than 8 dB.
- Gigabit Ethernet port for ultra-fast network speeds
- With a single wavelength of light, the single mode fibre optic can carry data and transmit audio/video applications over miles of distance
- Supports optical fibre cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- With 1000Base-ZX technology, enjoy up to 1000Mbps data transfer rate over optical fibre cable
Technical Specifications
| Total Number of Ports | 1 |
| Additional Information |
|
| Product Type | SFP (mini-GBIC) |
| Manufacturer Part Number | GLC-ZX-SM-RGD= |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | GLC-ZX-SM-RGD= |
| Product Name | 1000Base-ZX Rugged SFP Module |
| Brand Name | Cisco |
| Application/Usage | Data Networking |
| Network Technology | 1000Base-ZX |
| Maximum Data Transfer Rate | 1 |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Weight (Approximate) | 75 g |
| Height | 8.5 mm |
| Width | 13.4 mm |
| Depth | 56.5 mm |
