IE 4000 16 X RJ45 10/100M 4 X 1G COMBO
IE 4000 16 X RJ45 10/100M 4 X 1G COMBO
Product Overview
IE 4000 16 X RJ45 10/100M 4 X 1G COMBO
The Cisco® Industrial Ethernet (IE) 4000 Series is the latest addition to our ruggedized switching platforms and provides superior high-bandwidth switching and proven Cisco IOS® Software-based routing capabilities for industrial environments. The IE 4000 Series delivers highly secure access and industry-leading convergence using the Cisco Resilient Ethernet Protocol (REP) and is built to withstand extreme environments while adhering to overall IT network design, compliance, and performance requirements.- Fast Ethernet technology gives ideal solution for extending network connections to conference rooms, labs, lobbies and department workgroups
- Featuring Fast Ethernet ports to speed up the transfer rate up to 100mb/sec of large files and digital assets across your network
- Rail mounting is ideal for factory areas, in vehicles and marine applications
- Supports layer 3 switching for enhanced performance and usability
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports optical fibre cable to span longer distances and provided high data transmission rates between servers and network components
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Cascade to other network devices through the uplink port to expand your local area network
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 16 ports
- Quickly and easily set up a wired network with 16 networking ports
Technical Specifications
Management & Protocols
| Manageable | Yes |
Network & Communication
| Layer Supported | 3 |
Power Description
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
I/O Expansions
| Expansion Slot Type | SFP |
| Number of SFP Slots | 4 |
| Shared SFP Slot | Yes |
| Total Number of Expansion Slots | 4.0 |
Physical Characteristics
| Weight (Approximate) | 2.88 kg |
| Form Factor | Rail-mountable |
| Height | 155.4 mm |
| Width | 155.4 mm |
| Depth | 129.3 mm |
Interfaces/Ports
| Modular | Yes |
| Uplink Port | Yes |
| Stack Port | No |
| Total Number of Network Ports | 16 |
| Port/Expansion Slot Details | 4 x Gigabit Ethernet Uplink |
| 16 x Fast Ethernet Network |
Media & Performance
| Network Technology | 10/100Base-T |
| 1000Base-X | |
| Ethernet Technology | Gigabit Ethernet |
| Fast Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber |
General Information
| Product Type | Ethernet Switch |
| Manufacturer Part Number | IE-4000-16T4G-E |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | IE-4000-16T4G-E |
| Product Name | IE-4000-16T4G-E Ethernet Switch |
| Product Series | 4000 |
| Brand Name | Cisco |
