16 SERIAL SOFTWARE SELECTABLE DUAL DC 24

16 SERIAL SOFTWARE SELECTABLE DUAL DC 24

16 SERIAL SOFTWARE SELECTABLE DUAL DC 24

Product Overview

16 Port Serial Console, software selectable, Dual DC PSU, 24 Port GbE Switch, 2x1GbE/Fiber SFP, 16GB flash, 4 Year Warranty

16 SERIAL SOFTWARE SELECTABLE DUAL DC 24 ETHERNET PORTS 2 GBE ETHERNET OR FIBER SFP 16GB FLASH V.92 MODEM
  • Smart OOB™ with embedded cellular
  • Failover to Cellular™
  • Flexible Connectivity - embedded cellular, PSTN, and redundant ethernet/fiber
  • Additional models with 24 Port switch and 24 Port USB Console
  • Simple cabling with software selectable Pin-outs
  • Hyperscale, Automation ZTP, API, Lighthouse
  • Powerful hardware with integrated 16 GB internal storage

Technical Specifications

Power Description
Input Voltage230 V AC
120 V AC
General Information
Product TypeInfrastructure Management Equipment
Manufacturer Part NumberIM7216-2-24E-DDC
Manufacturer Website Addresshttp://www.opengear.com
ManufacturerOpengear
Product ModelIM7216-2-24E-DDC
Product NameIM7216-2-24E-DDC Infrastructure Management Equipment
Product SeriesIM7200
Brand NameOpengear
Miscellaneous
Additional Information
    • 16 x RJ45 RS-232 Software Selectable Console Ports and 24 Port Gigabit Switch
    • Ethernet Ports: 2 x 10/100/1000 Ethernet/SFP Fiber port with 1500V AC Isolation and ESD Protection
    • Console Port: 1 x RJ45 RS-232 Console Port
    • PSTN Modem: 1 x Internal V.92 modem with RJ11 Socket
    • Serial Ports: Software Selectable 50 to 230,400 bps
    • CPU: 1 GHz ARM SoC (Marvell 88F6283)
    • Operating Temperature: 5°C to 50°C, 41°F to 122°F
    • Storage Temperature: -30°C to +60°C, -22°F to +140°F
    • Humidity: 5% to 90%
    • Environmental Monitoring: Serial EMD5000 to support physical, smoke, water leak and vibration sensors
    Memory:
    • 256 MB DDR2 SDRAM
    • 64 MB Embedded NOR Flash
    Security, Encryption & Authentication:
    • SSH
    • FIPS-140-2 compliant Open SSL Module
    • Strong ciphers -AES encryption
    • Cisco-compatible IPsec
    • OpenVPN
    • AAA - TACACS+, RADIUS, Active Directory/OpenLDAP, Kerberos, with local fallback
    • Two factor authentication via remote AAA
    • Configurable stateful firewall
    • Actively developed & support and security notifications-frequent firmware updates
Application/UsageRemote Management
Package Contents
  • IM7216-2-24E-DDC Infrastructure Management Equipment
  • Rack Mount Kit - 2 x Ears and Screws
  • 1 x Cisco Straight DB9F-RJ45 Adapter
  • 1 x CAT5 Patch Cable 5'
  • Quick Start Guide
Certification
    Emissions:
    • FCC Part 15 Subpart B (Class A)
    • ICES-003 Issue 5 (2014)
    • AS/NZS CISPR 22: 200410 (Class A)
    • EN 55032:2015 (Class A)
    • EN 61000-3-2 Harmonics Current Emissions (2014)
    • EN 61000-3-3 Voltage Fluctuation and Flicker (2013)
    Immunity:
    • EN 55024 ITE Immunity (2010)
    • IEC 61000-4-2 (2008)
    • IEC 61000-4-3 (2006) A1 (2007) A2 (2010)
    • IEC 61000-4-4 (2012)
    • IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013, C-Tick
    • IEC 61000-4-5 (2014)
    • IEC 61000-4-6 (2014)
    • IEC 61000-4-8 (2010)
    • IEC 61000-4-11 (2004)
