Product Overview
IW-PLG Pedestal Server Chassis for High Performance GPU Workstation - 4 Bays
IW-PLG Tower
Excellent Performance Computing Workstation for GPU Applications
Multi-GPU Computing WorkstationThe InWin IW-PLG Tower is a professional workstation designed for SMB servers, 3D rendering, virtualization, healthcare data center and AI applications. Supporting the latest Intel®Xeon Scalable & AMD EPYC processors, the IW-PLG Tower offers high levels of performance, reliability and availability.
- Compliance for Intel<sup>®</sup>Xeon Scalable / AMD EPYC family
- 9 expansion slots supporting up to 4 x full-height, full-length, double-width GPU cards
- Screwless adjustable card holder for full-height GPU cards
- High efficiency CRPS modules with PDB (80 Plus Platinum 800W/1200W/1600W/2000W)
- Supports maximum 14 x 2.5" SSD drives (including internal 2.5" x 2)
- Built-in 2.5"/3.5" HDD 4-bay backplane with SAS/SATA/NVMe module (max. support x 3)
- Pre-installed 92mm middle fans x 3 and 120mm rear fan x 1 (80mm rear fan kit optional)
- Supports rack installation by slide rails
- Lockable front and side panel
Technical Specifications
I/O Expansions
| Total Number of Expansion Slots | 9 |
Bays
| "Number of External 5.25"" Bays" | 1 |
| "Number of Internal 2.5"" Bays" | 2 |
| "Number of Internal 3.5"" Bays" | 1 |
| "Number of External 2.5""/3.5"" Bays" | 12 |
General Information
| Product Type | Server Case |
| Manufacturer Part Number | IW-PLG.4BAYS |
| Manufacturer Website Address | http://www.in-win.com.tw/Corporate/zh/ |
| Manufacturer | In Win Development, Inc |
| Product Name | High Performance GPU Workstation |
| Brand Name | In Win |
Physical Characteristics
| Weight (Approximate) | 16.95 kg |
| Form Factor | Pedestal |
| Cooler Type | Fan Cooler |
| Height | 430 mm |
| Width | 200 mm |
| Depth | 589.7 mm |
| Product Color | Multicolor |
| Maximum CPU Cooler Height | 145 mm |
| Color Family | Multicolor |
| Product Material | Galvanized Cold Rolled Steel (SGCC) |
| Maximum GPU Length | 330 mm |
Technical Information
| Motherboard Supported | SSI CEB |
| SSI EEB | |
| ATX | |
| Features | Padlock Loop |
| Kensington Lock | |
| Cable Management | |
| Reset Button | |
| On/Off Button | |
| Number of Fans Installed | 4 |
| Installed Fan Size | 92 mm |
| 120 mm |
