KTG SD5000T5 TB5 TRIPLE 4K PD DOCK
KTG SD5000T5 TB5 TRIPLE 4K PD DOCK
Product Overview
Kensington SD5000T5 Thunderbolt 5 Docking Station for Workstation/Notebook/Monitor - Charging Capability - Memory Card Reader - SD - Desktop - 3 Displays Supported - 8K @ 60Hz, Full HD, 4K @ 144Hz - 7680 x 4320, 3840 x 2160, 1920 x 1080 - 3 x USB Ports - 3 x USB Type-A Ports - USB Type-A - Network (RJ-45) - Thunderbolt - Wired - 2.5 Gigabit Ethernet - Windows 11, macOS Sonoma 14.5 - 140W
Features | Boost Your Productivity with Thunderbolt™ 5
The SD5000T5 offers lightning-fast data transfers, achieving speeds up to 80Gbps and Bandwidth Boost providing up to 120Gbps for video-intensive usage.
Recycled Materials
Composed of 100% post-consumer recycled (PCR) aluminum*- and delivered in Forest Stewardship Council (FSC®) certified packaging. *The outer casing of the docking station is made of aluminum.
Triple 4K or Dual 8K Support
Supporting up to three 4K monitors @ 144Hz or two 8K monitors @ 60Hz, the SD5000T5 supports uncompromised visual quality and smooth multitasking for a high-performance workspace.
Up to 140W Power Delivery
Perfect for demanding workstations, the single-cable Thunderbolt™ 5 solution ensures seamless power and connectivity with up to 140W Power Delivery.
Productive 11-in-1 Design
3 x Thunderbolt™ 5 downstream ports, 1 x Thunderbolt™ 5 host, 3 x USB-A 3.2 Gen2 10Gbps ports, a combo audio jack, dual SD/Micro Card readers, and 2.5Gbps Ethernet for seamless productivity.
Built-in SD and Micro SD Card Readers
Perfect for graphic designers, video editors, and animators requiring fast and efficient data transfer speeds, the SD5000T5 transfers files at ultra-fast speeds via built in UHS-II SD and Micro SD card readers.
Universal Compatibility
Offers a quick and powerful plug-and-play solution for Thunderbolt™ 5, Thunderbolt™ 4, USB4®, and USB-C® devices running Windows 11 (23H2 or later) or macOS (14.5 or later).
Zero-Footprint Mounting Option and Security Cable Lock Slots
Maximize desktop space by mounting your docking station out of the way. Protect your investment with a Kensington cable lock (K65020EU or K65021WW), sold separately.
Free Kensington DockWorks™ Software and 3-Year Limited Warranty
Free DockWorks™ software delivers the best connection, performance, and security from your Kensington dock. Enjoy peace of mind knowing your covered by Kensington with a professional warranty.
Technical Specifications
| Kensington Security Slot | Yes |
| Device Supported | Workstation/Notebook/Monitor |
| Connectivity Technology | Wired |
| Features | Cable Lock Slot |
| Card Reader | |
| Plug and Play | |
| Security Lock | |
| USB- Power Delivery (USB PD) | |
| Charging Capability | Yes |
| Memory Card Supported | microSD |
| SD | |
| Memory Card Reader | Yes |
| Maximum Data Transfer Rate | 15 GB/s |
| Number of Displays Supported | 3 |
| Supported Resolutions | 7680 x 4320 |
| 3840 x 2160 | |
| 1920 x 1080 | |
| Screen Mode Supported | Full HD |
| 8K @ 60Hz | |
| 4K @ 144Hz | |
| Security Slot Type | Kensington Security Slot |
| Ethernet Technology | 2.5 Gigabit Ethernet |
| Form Factor | Desktop |
| Operating System Supported | macOS Sonoma 14.5 |
| Windows 11 |
| Product Type | Docking Station |
| Manufacturer Part Number | K35201AP |
| Manufacturer Website Address | http://www.acco.com.au |
| Manufacturer | ACCO Brands Corporation |
| Product Model | SD5000T5 |
| Product Name | SD5000T5 EQ Thunderbolt 5 Triple 4K Docking Station with 140W PD - Windows/macOS |
| Brand Name | Kensington |
| Host Interface | Thunderbolt 5 |
| Network (RJ-45) | Yes |
| Total Number of USB Ports | 3 |
| Thunderbolt | Yes |
| Headphone/Microphone Combo Port | Yes |
| Number of USB Type-A Ports | 3 |
| Thunderbolt Ports Quantity | 4 |
| USB Power Delivery | 140W |
| Number of USB 3.2 Gen 2 Type-A Ports | 3 |
| USB Type-A | Yes |
