KTG SD5900T TB4 QUAD 4K DOCK 96W PD

KTG SD5900T TB4 QUAD 4K DOCK 96W PD

KTG SD5900T TB4 QUAD 4K DOCK 96W PD

Product Overview

Kensington SD5900T Thunderbolt 4 Docking Station for Notebook/Monitor - Charging Capability - Memory Card Reader - SD - Midnight Blue - Desktop - 4 Displays Supported - 4K, 4K @ 60Hz - 3840 x 2160 - 4 x USB Ports - 3 x USB Type-A Ports - USB Type-A - 1 x USB Type-C Ports - USB Type-C - 1 x RJ-45 Ports - Network (RJ-45) - 2 x HDMI Ports - HDMI - 3 x DisplayPorts - DisplayPort - Thunderbolt - Wired - 2.5 Gigabit Ethernet - Mac OS X 11.0 Big Sur, Windows - 100W - 2 x Thunderbolt 4 Ports

Up to Quad 4K Video via HDMI®, DP, and Thunderbolt™ for MacBook

Provides flexible video connections without the need for cumbersome adapters. Choose between 2 x Thunderbolt™ 4 downstream ports and 1 x DP port for plug-and-play video. Add 2 x HDMI®/DP options with DisplayLink® technology. Supports up to quad 4K @ 60Hz for MacBook M1/M2/ M3 with Pro and Max chipsets (and M3 base chipset with laptop lid closed). Also supports up to triple 4K @ 60Hz for base M1/M2 chipsets.

Designed for MacBook

Delivers the power of Thunderbolt™ 4, reflects the midnight blue aesthetic of the latest MacBook, and is optimized for devices with M1, M2, and M3 chipsets running macOS (11 or later).

Thunderbolt™ 4 Hybrid Technology

Combines Thunderbolt™ with DisplayLink® technology to provide next-level productivity experiences. Transfers up to 40Gbps of data, video, and audio. Provides daisy chain support for SSDs, monitors, and other Thunderbolt™ devices. Blocks peripheral devices from unauthorized access to system memory using Intel VT-d DMA protection.

Up to 100W Charging (96W certified)

Power your MacBook while also charging your connected accessories, including iPhones, AirPods, and Apple watches. Includes KonstantCharge™, enabling connected devices to charge even when your MacBook is undocked.

Productive 16-in-1 Design

With 16 connection options, provides all the ports you need to get the job done today and well into the future. Includes 1 x Thunderbolt™ host port and 2 x Thunderbolt™ 4 downstream ports capable of data, video, and audio, 1 x USB-C® 3.2 Gen2 10Gbps, 1 x USB-A 3.2 Gen2 10Gbps, 2 x USB-A 3.2 Gen1 5Gbps, 2 x HDMI®/DP, 1 x DP, 1 x 3.5mm combo audio jack, 1 x SD Card reader, 1 x Micro SD Card reader, and 1 x 2.5Gbps Ethernet.

Recycled Materials

The SD5900T is composed of 100% post-consumer recycled (PCR) aluminum* and it is delivered in Forest Stewardship Council (FSC®) certified packaging. *The outer casing of the docking station is made of aluminum. The PCBA and any related inner components are not made of aluminum.

Zero-Footprint Mounting Option and Security Cable Lock Slots

Maximize desktop space by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Protect your investment with a Kensington cable lock (K65020WW or K65021WW), sold separately.

3-Year Limited Warranty

Enjoy peace of mind knowing you are covered by Kensington with a professional warranty.

Technical Specifications

Network & Communication
Ethernet Technology2.5 Gigabit Ethernet
Software
Operating System SupportedMac OS X 11.0 Big Sur
Windows
Physical Characteristics
Form FactorDesktop
Product ColorMidnight Blue
Color FamilyBlue
Miscellaneous
Compatibility

Compatible with Apple MacBook models with M1, M2, and M3 chipsets

Post-consumer-waste%100%
Brand CompatibilityApple
Kensington Security SlotYes
Interfaces/Ports
Host InterfaceThunderbolt 4
HDMIYes
Number of HDMI Ports2
Network (RJ-45)Yes
DisplayPortYes
Total Number of USB Ports4
ThunderboltYes
Number of DisplayPorts3
Headphone/Microphone Combo PortYes
Number of RJ-45 Ports1
USB Type-CYes
USB Type-C Detail1 x USB-C® 3.2 Gen2 10Gbps
Number of USB Type-C Ports1
Number of USB Type-A Ports3
Thunderbolt Ports Quantity2
USB Power Delivery100W
Number of USB 3.2 Gen 1 Type-A Ports2
Number of USB 3.2 Gen 2 Type-A Ports1
Number of Thunderbolt 4 Ports2
USB Type-AYes
General Information
Product TypeDocking Station
Manufacturer Part NumberK35232AP
Manufacturer Website Addresshttp://www.acco.com.au
ManufacturerACCO Brands Corporation
Product ModelSD5900T
Product NameSD5900T Docking Station
Brand NameKensington
Technical Information
Device SupportedNotebook/Monitor
Connectivity TechnologyWired
FeaturesSecurity Lock
Card Reader
Cable Lock Slot
Plug and Play
Charging CapabilityYes
Memory Card SupportedSD
microSD
Memory Card ReaderYes
Maximum Data Transfer Rate5 GB/s
Number of Displays Supported4
Supported Resolutions3840 x 2160
Screen Mode Supported4K @ 60Hz
4K
Security Slot TypeKensington Security Slot
