LTE ARTICULATING DIPOLE ANTENNA 698-960

LTE ARTICULATING DIPOLE ANTENNA 698-960 1448-1511 1710-2690

For optimal performance, we strongly recommend that you use two antennas to take full advantage of MIMO technology on all Cisco cellular routers that support MIMO (4G LTE and later releases).The LTE-ANTM-D omnidirectional dipole antenna is designed for indoor use with Cisco 4G Long Term Evolution (LTE) and Long Term Evolution Advanced (LTEA) Network Interface Modules (NIMs), 4G and 4G LTE Enhanced High-Speed WAN Interface Cards (EHWICs) as well as Cisco 4G and 3G Integrated Service Routers (ISRs).

The LTE-ANTM-D antenna is marked with a dual green band to indicate that it supports Cisco LTEA routers and modules.

This antenna has the following features:

• Support for frequencies of 698-960, 1448-1511, and 1710-2690 MHz.
• Standalone antenna peak gain of less than 3.7 dBi in the supported frequency bands.
• Articulating joint that can maneuver into three stop positions: 0°, 45°, and 90°.
• Male Threaded Neill-Concelman (TNC) connector that allows direct mounting of the antenna to any Cisco supported router with a female TNC connector.

For optimal performance, we strongly recommend that you use two antennas to take full advantage of MIMO technology on all Cisco cellular routers that support MIMO (4G LTE and later releases).
