APL-LOW VOLTAGE 12VDC 24VAC INPUT
APL-LOW VOLTAGE 12VDC 24VAC INPUT
Product Overview
APL-LOW VOLTAGE 12VDC 24VAC INPUT
The Cisco Meraki MA-PWR-MV-LV is a unique accessory that converts existing low voltage (12/24V) power supplies into PoE, allowing users to upgrade from analog to IP in just a few simple steps. Twin power cables can be disconnected from an analog camera and connected to the two terminals within the accessory in either order. The coaxial cable from the analog camera can simply be left in the wall and will no longer be used. Instead, video data will transmit wirelessly from the camera to the viewing computer (local connection) or through the Meraki cloud (for video proxy to a remote viewing device
Technical Specifications
| Form Factor | Wall Mountable |
| Input Ports | 1 x 1000Base-T |
| Output Ports | 1 x PoE |
| Product Type | PoE Injector |
| Manufacturer Part Number | MA-PWR-MV-LV |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Name | Low Voltage 12VDC/24VAC Input PoE Injector for MV Cameras (Coax Converted) |
| Brand Name | Meraki |
| Package Contents |
|
| Compatibility | Meraki MV12 Cloud Managed Security Camera |
| Certifications & Standards | IEEE 802.3af |
| Input Voltage | 24 V AC |
| 12 V DC | |
| Maximum Output Voltage | 54 V DC |
