Product Overview

Meraki Fixed Lens MV63 Mini-dome Outdoor 4K Camera- 256GB

The Meraki MV63, part of the third generation of MV smart cameras, combines physical security and advanced analytics in a powerful, yet compact fixed-lens mini dome form factor. With an edge architecture that minimizes physical infrastructure and software requirements, MV63 enables faster, easier deployments and greater scalability.

Security in high definition

The ultra-high-performance MV63 series camera supports up to 4K resolution for highdefinition video, delivering the level of detail needed to stay on top of what matters.With IK10+ and IP67 ratings, plus IR illumination, the MV63 extends visibility and safety to outdoor and demanding environments

Compact and easy to install, MV63 series cameras are compatible with a variety of mounting accessories, delivering the right viewing angle wherever they are placed. MV63 series cameras are ideal for monitoring entrances and exits, as well as the general perimeter, from walls, ceilings, or even corner-mount locations.

Using machine-learning based computer vision, MV63 cameras can perform real-time object detection, classification, and tracking of people and vehicles to increase safety and provide useful insights into activity. These smart cameras deliver powerful business intelligence without compromising physical security

  • Fixed lens mini-dome camera
  • Compact form factor with 102° horizontal FoV
  • More detailed information with up to 4K resolution
  • Night vision with IR illumination up to 20 m (66 ft)
  • IK10+ and IP67 for deployment in outdoor and demanding environments
  • Intelligent motion indexing with search engine
  • Built-in analytics like motion search, motion recap, and motion heatmaps
  • Machine-learning capability for intelligent object detection
  • Secure video access to ensure privacy with role-based user accounts
  • Cloud-augmented edge storage for minimal physical infrastructure
  • CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
  • For remote surveillance needs, this network camera is best suited
  • Network camera - Helps achieve high-quality video results
  • Up to 3854 x 2176 resolution for surveillance in real-time
  • Up to 3854 x 2176 video resolution
  • Provides night vision of objects at a distance of up to 20 m

Technical Specifications

Interfaces/Ports
Network (RJ-45)Yes
Power Description
Power Source TypePoE
Storage
Solid State Drive Capacity256 GB
Exposure
Longest Shutter Speed1/30 Second
Shortest Shutter Speed1/32000 Second
Network & Communication
Connectivity TechnologyWired & Wireless
Remote ManagementYes
Video
Video FormatsH.264
Maximum Video Resolution3854 x 2176
Maximum Frame Rate24 fps
Display & Graphics
Color SupportedColour
Image Sensor TypeCMOS
Effective Camera Resolution8.4 Megapixel
Field of Viewhorizontal 102°
Physical Characteristics
Weight (Approximate)920 g
Form FactorMini Dome
Mount TypeBox Mount
Pole Mount
Pendant Mount
Corner Mount
Conduit Mount
Ceiling Mount
Wall Mount
Diameter131 mm
Height95 mm
Lens
Lens TypeFixed
Maximum Aperturef/2.0
Maximum Focal Length3.30 mm
Lens IncludedYes
Technical Information
Night VisionYes
HD RecordingYes
Night Vision Distance20 m
Night Vision TypeInfrared
General Information
Product TypeNetwork Camera
Manufacturer Part NumberMV63-HW
Manufacturer Website Addresshttp://www.cisco.com/c/en_au
ManufacturerCisco Systems, Inc
Product ModelMV63X
Product NameMV63 Cloud-Managed Smart Camera
Brand NameMeraki
Miscellaneous
FeaturesBuilt-in Infrared Illuminator
Day/Night
Built-in Microphone
Built-in IR LED
Indoor/OutdoorOutdoor
Impact Protection RatingIK10+
Ingress Protection RatingIP67
