NEXUS 9200 WITH 48P 100M/1GT 4P 10/25G
NEXUS 9200 WITH 48P 100M/1GT 4P 10/25G
Product Overview
NEXUS 9200 WITH 48P 100M/1GT 4P 10/25G
The Cisco Nexus 92348GC-X Switch is a 1RU switch based on Cisco Cloud Scale technology and supports 0.696 Tbps of bandwidth and over 250 mpps. The 48 1GBASE-T downlink ports on the 9248GC-X can be configured to work as 100-Mbps, 1-Gbps ports. The 4 ports of SFP28 can be configured as 1/10/25-Gbps and the 2 ports of QSFP28 can be configured as 40- and 100-Gbps ports. The Cisco Nexus 92348GC-X is ideal for big data customers that require a Gigabit Ethernet ToR switch with local switching and for management switch use cases.
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Supports layer 3 switching for enhanced performance and usability
- Managed switch provides a reliable foundation for your network
- Management capability provides control over setup and configuration of your network
- Supports cost-efficient twisted pair cables for high-speed data transfer up to 100 meters
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Cascade to other network devices through the uplink port to expand your local area network
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 48 ports
- Quickly and easily set up a wired network with 48 networking ports
Technical Specifications
Management & Protocols
| Manageable | Yes |
Network & Communication
| Layer Supported | 3 |
Miscellaneous
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Power Description
| Power Source | Power Supply |
| Redundant Power Supply Supported | Yes |
I/O Expansions
| Expansion Slot Type | SFP28 |
| QSFP28 | |
| Total Number of Expansion Slots | 6.0 |
Interfaces/Ports
| Modular | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 48 |
| Port/Expansion Slot Details | 48 x Gigabit Ethernet Network |
| 4 x 25 Gigabit Ethernet Expansion Slot | |
| 2 x 100 Gigabit Ethernet Expansion Slot |
Physical Characteristics
| Weight (Approximate) | 6.40 kg |
| Form Factor | Rack-mountable |
| Height | 43.7 mm |
| Width | 439.4 mm |
| Depth | 469.9 mm |
| Compatible Rack Unit | 1U |
Media & Performance
| Network Technology | 10/100/1000Base-T |
| 100GBase-X | |
| 25GBase-X | |
| Ethernet Technology | 100 Gigabit Ethernet |
| Gigabit Ethernet | |
| 25 Gigabit Ethernet | |
| Media Type Supported | Optical Fiber |
| Twisted Pair |
General Information
| Product Type | Ethernet Switch |
| Manufacturer Part Number | N9K-C92348GC-X |
| Manufacturer Website Address | http://www.cisco.com/c/en_au |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 92348GC-X |
| Product Name | Nexus 92348GC-X Ethernet Switch |
| Product Line | Nexus |
| Product Series | 9200 |
| Brand Name | Cisco |
