Product Overview

CyberPower OLS10KERT5U Double Conversion Online UPS - 10 kVA/10 kW - Single Phase - 5U Rack/Tower - 4 Hour Recharge - 2.90 Minute Stand-by - 120 V AC, 230 V AC Input - 200 V AC, 208 V AC, 220 V AC, 230 V AC, 240 V AC Output - 1 x Terminal Block - Pure Sine Wave - Serial Port - LCD/LED Display

CyberPowerOLS10KERT5U is a high-efficiency UPS featuring online double-conversion topology, which provides seamless Pure Sine Wave power for mission-critical devices such as NAS, servers, DVRs/surveillance systems, transportation, infrastructure, and emergency systems. It's typically integrated into the back office, server room, and data center environment.

With high output power factor, the UPS in a smaller footprint can provide more usable power and save rack space. The product allows multiple UPS units to be connected in parallel, achieving higher capacity and power redundancy. The pre-installed Maintenance Bypass PDU (MBP) offers quick and safe maintenance without power interruption. Moreover, the UPS is equipped with Remote Cloud Card to support remote monitoring via a web portal and the mobile app. The tiltable color LCD comes with an intuitive and graphical interface, allowing users to monitor and configure settings with ease. Besides, the battery charging current is adjustable via LCD setting to shorten charging time. It is also designed with relay-type dry contact port to support specific UPS event notifications for easy management.

  • Online (Double Conversion) UPS Topology
  • High Output Power Factor
  • Overload Protection
  • Maintenance Bypass Switch
  • Extended Battery Module Auto-detection
  • User-replaceable Batteries
  • Tiltable LCD Panel
  • Relay-type Dry Contact
  • SNMP/HTTP Remote Management Capability (Optional)
  • ECO Mode
  • Pure Sine Wave Output
  • Zero Transfer Time
  • Extended Battery Module (EBM)
  • Adjustable Charging Current
  • Color LCD Panel
  • Emergency Power Off (EPO) Port
  • PowerPanel Management Software
  • Rack/Tower Convertible Configurations

Technical Specifications

Controls/Indicators
Status Indicators

    LCD Information Display:

    • Operation Type
    • Power Status
    • Battery Status
    • Load Status
    • Fault & Warning
    • Other Information
    • Event & Log

    LED Indicators:

    • Power On
Display & Graphics
DisplayLCD/LED
Interfaces/Ports
Serial PortYes
EPO PortYes
USB (HID Compliant) PortYes
Miscellaneous
Package Contents
  • OLS10KERT5U 10000VA Rack/Tower UPS
  • External Maintenance Bypass PDU
  • Rackmount Rail
  • Rackmount Ears
  • Rail Kit
  • Screw Kit
  • Power Cord
  • USB Cable
  • Phone Line
  • User's Manual
Environmentally FriendlyYes
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
Environmental Conditions
Thermal Dissipation2047 BTU/h
Maximum Operating Temperature40°C
Maximum Operating Elevation1.50 km
Maximum Storage Elevation15 km
Sound Emission (A-Weighted)62 dB(A)
Battery Information
Battery ChemistryLead Acid
Backup/Run Time (Half Load)11.20 Minute
Backup/Run Time (Full Load)2.90 Minute
Battery CharacteristicsHot-swappable/Sealed
Replaceable BatteryYes
Typical Battery Recharge Time4 Hour
General Information
Product TypeDouble Conversion Online UPS
Manufacturer Part NumberOLS10KERT5U
Manufacturer Website Addresshttps://www.cyberpower.com/au
ManufacturerCyberPower Systems, Inc
Product ModelOLS10KERT5U
Product NameOLS10KERT5U 10000VA Rack/Tower UPS
Brand NameCyberPower
Power Description
Input Voltage230 V AC
120 V AC
Output Voltage208 V AC
220 V AC
240 V AC
230 V AC
200 V AC
Surge Energy Rating1335 J
Waveform TypePure Sine Wave
Input Voltage Range110 V AC - 300 V AC
Output Frequency60 Hz
Input Frequency60 Hz
Load Capacity (VA)10 kVA
Load Capacity (Watt)10 kW
Input Power Factor0.99
Output Power Factor1
Physical Characteristics
Form FactorRack/Tower
Rack Height5U
Height213.5 mm
Width433 mm
Depth661 mm
Product ColorBlack
Color FamilyBlack
Management
Network ManagementSNMP/HTTP Remote Monitoring
AlarmLow Battery
Battery Mode
Over Charge
Overheat
UPS Fault
Replace Battery
Overload
Technical Information
Application/UsageDVR
Surveillance System
Server
Office
NAS Storage Device
Mission Critical Equipment
Server Room
Data Center
Transportation
Emergency System
Infrastructure
Overload ProtectionYes
Plug/Connector TypeTerminal Block
PhaseSingle Phase
Receptacle TypeTerminal Block
EMI/RFI Noise FilterYes
Receptacle Detail1 x Terminal Block

Price Trend

Current Price
AUD 6,999.09
