Product Overview

CyberPower Online S OLS3S15KE Double Conversion Online UPS - 1.50 kVA/1.35 kW - Tower - 8 Hour Recharge - 6.40 Minute Stand-by - 230 V AC, 380 V AC, 400 V AC, 415 V AC Input - 208 V AC, 220 V AC Output - 1 x Hardwired - Three Phase - Serial Port - 1 x Battery/Surge Outlet

CyberPower OLS3S15KE guarantees power backup protection for IT equipment, servers, workstations, NAS/Storage devices, telecom devices, networking devices, security/emergency systems, and surveillance systems. The UPS adopts double-conversion topology to provide high-quality power output with additional ECO Mode to conserve power and save on energy costs. The UPS supports parallel expansion to allow the connections of multiple UPS units, achieving system redundancy. It is compatible with generators to prolong power continuity, and maintenance bypass switch to provide quick and safe maintenance without having to shut down UPS and connected equipment. The product can be connected to Emergency Power Off (EPO) switch, allowing users to shut off UPS immediately during emergency.

The UPS can employ Extended Battery Modules (EBM) to prolong runtimes, and its built-in Smart Battery Management (SBM) enhances battery charging process to extend battery lifetime. This model also features multifunction LCD readout to display information of power and battery conditions. The PowerPanel® Power Management Software allows user to perform real-time monitoring and remote management of the UPS.

  • Three-phase Design
  • ECO Mode
  • Dual Inputs
  • Pure Sine Wave Output
  • LCD Status Display
  • Battery Cold Start
  • Smart Battery Management (SBM)
  • PowerPanel® Management Software
  • Online (Double Conversion) UPS Topology
  • UPS Parallel Expansion

Technical Specifications

Controls/Indicators
Status Indicators

    LCD Information Display:

    • Operation Type
    • Power Status
    • Battery Status
    • Load Status
    • Fault & Warning
    • Other Information
    • Event & Log

    LED Indicators:

    • Line Mode
    • Battery Mode
    • Bypass Mode
    • UPS Fault
Miscellaneous
Package Contents
  • Online S OLS3S15KE 1.5kVA Tower UPS
  • Parallel Port Cover Plate
  • Terminal Cover
  • Terminal Splices
  • USB Cable
  • User's Manual
  • Product Registration Card
Environmentally FriendlyYes
Interfaces/Ports
Serial PortYes
EPO PortYes
USB (HID Compliant) PortYes
Environmental Conditions
Thermal Dissipation3487 BTU/h
Maximum Operating Temperature40°C
Maximum Operating Elevation2 km
Maximum Storage Elevation15 km
Sound Emission (A-Weighted)60 dB(A)
Physical Characteristics
Weight (Approximate)172 kg
Height890 mm
Width350 mm
Depth650 mm
Product ColorBlack
Color FamilyBlack
Management
Network ManagementSNMP/HTTP Remote Monitoring
AlarmLow Battery
Overload
Battery Mode
UPS Fault
Over-charge
Overheat
Power Description
Input Voltage400 V AC
415 V AC
230 V AC
380 V AC
Output Voltage240 V AC
230 V AC
220 V AC
208 V AC
Surge Energy Rating445 J
Waveform TypePure Sine Wave
Input Voltage Range305 V AC - 478 V AC
176 V AC - 276 V AC
Output Frequency60 Hz
Input Frequency60 Hz
Load Capacity (VA)1.50 kVA
Load Capacity (Watt)1.35 kW
General Information
Product TypeDouble Conversion Online UPS
Manufacturer Part NumberOLS3S15KE
Manufacturer Website Addresshttps://www.cyberpower.com/au
ManufacturerCyberPower Systems, Inc
Product ModelOLS3S15KE
Product NameOnline S OLS3S15KE 1.5kVA Tower UPS
Product LineOnline S
Brand NameCyberPower
Battery Information
Battery ChemistryLead Acid
Battery Size12V
Battery Capacity9000 mAh
Number of Batteries20
Backup/Run Time (Half Load)15.30 Minute
Backup/Run Time (Full Load)6.40 Minute
Battery CharacteristicsValve-regulated
DC System Voltage240 V DC
Typical Battery Recharge Time8 Hour
Number of External Battery Cabinets40
Technical Information
Application/UsageTelecommunication
Workstation
Surveillance System
Server
Security System
Network Storage Device
IT Equipment
Emergency System
Data Center
Overload ProtectionYes
Plug/Connector TypeHardwired
PhaseThree Phase
EMI/RFI Noise FilterYes
Energy SavingOnline ECO Mode Efficiency > 97%
Number of Battery & Surge Outlets1
Transfer Time0 ns
Receptacle Detail1 x Hardwired

Price Trend

Current Price
AUD 8,199.09
