HPE MICROSVR G10+ V2 G6405 16G NHP SVR
HPE MICROSVR G10+ V2 G6405 16G NHP SVR
Product Overview
HPE ProLiant MicroServer Gen10 Plus v2 Ultra Micro Tower Server - 1 x Intel Pentium Gold G6405 4.10 GHz - 16 GB RAM - Serial ATA/600 Controller - Intel C252 Chip - 1 Processor Support - 64 GB RAM Support - DDR4 SDRAM - Gigabit Ethernet - 4 x LFF Bay(s) - 1 x 180 W
HPE ProLiant MicroServer Gen10 Plus v2
HPE ProLiant MicroServer Gen10 Plus v2 delivers an affordable compact yet powerful entry level server that you can customize for on-premises, hybrid cloud, or even workloads demanding datacenter performance. It has the same design as the previous version and can be placed flat or vertically depending on customer environment. The latest Intel Xeon® E and Pentium® supported processors deliver compute performance as well as security and remote management into the server with HPE iLO silicon root of trust. Along with other enhancements such as 4x 1GbE onboard NICs and USB 3.2 Gen2 Type-A, whether you want a general- purpose server, NAS or even a virtualization server, you will be surprised at how much you can get out of this small and affordable server.
- Gigabit Ethernet enables higher aggregate data transfer capacity resulting in better overall performance
- RAID provides data reliability, fault tolerance and improves overall performance
- 1 x 180 W power supply unit (PSU) included
- With 16 GB memory, you can multitask between applications smoothly
Technical Specifications
| Total Hard Drive Capacity | No |
| Additional Warranty Information | 1/1/1 - Server Warranty includes one years of parts, one year of labor, one year of onsite support coverage with NBD response |
| Chipset Manufacturer | Intel |
| Chipset Model | C252 |
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Controller Model | VROC |
| Security Features |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Number of Total Expansion Bays | 4 |
| "Number of 3.5"" Bays" | 4 |
| Total Number of Expansion Slots | 1.0 |
| Hot Swappable Bays | No |
| Number of LFF Bays | 4 |
| Weight (Approximate) | 7.20 kg |
| Form Factor | Ultra Micro Tower |
| Height | 118.9 mm |
| Width | 245.1 mm |
| Depth | 245.1 mm |
| Power Source | AC Adapter |
| Number of Power Supplies Supported | 1 |
| Number of Power Supplies Installed | 1 |
| Redundant Power Supply | No |
| Maximum Power Supply Wattage | 180 W |
| Product Type | Server |
| Manufacturer Part Number | P54644-371 |
| Manufacturer Website Address | https://www.hpe.com/au/ |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | ProLiant MicroServer Gen10 Plus V2 Server |
| Product Line | ProLiant |
| Product Series | MicroServer Gen10 Plus v2 |
| Brand Name | HPE |
| Error Checking | ECC |
| Maximum Memory Supported | 64 GB |
| Standard Memory | 16 GB |
| Memory Technology | DDR4 SDRAM |
| Number of Occupied Memory Slots | 1 |
| Memory Clock Speed | 3.20 GHz |
| Total Number of Memory Slots | 2.0 |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 4 |
| Network (RJ-45) | Yes |
| DisplayPort | Yes |
| Total Number of USB Ports | 7 |
| Number of USB 2.0 Ports | 1 |
| Number of VGA Ports | 1 |
| Number of DisplayPorts | 1 |
| Cache | 4 MB |
| Processor Speed | 4.10 GHz |
| Processor Type | Pentium Gold |
| Processor Model | G6405 |
| Processor Core | Dual-core (2 Core) |
| Processor Manufacturer | Intel |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Operating System | No |
| Operating System Supported | Windows Server 2022 Standard |
| Windows Server 2022 Essentials | |
| Windows Server 2022 Datacenter | |
| Windows Server 2019 Standard | |
| Windows Server 2019 Essentials | |
| Windows Server 2019 Datacenter | |
| Hyper-V | |
| Red Hat Enterprise Linux 8.4 |
