SFP+ Card 10 Gbps - Fiber Copper DAC
SFP+ Card 10 Gbps - Fiber Copper DAC
Product Overview
StarTech.com PEX10GSFP 10Gigabit Ethernet Card for Computer Case - 10GBase-X - SFP+ - Plug-in Card - Up to 10 Gbps PCIe network card - MSA compliant SFP+ slot - Eliminate EMI using Fiber - MMF/SMF/Copper Support - 9K Jumbo - Link Aggregation - VLAN tagging - PCIe 3.0 x4 - DAC support - Full Duplex - Low Profile Bracket incl. - Windows/Linux
Increase your network speed
This PCIe network card lets you take advantage of improved bandwidth in data-intensive applications such as multimedia streaming and large file transfers. This fiber NIC offers data transfer rates of up to 10Gbps which improve speeds and reduces load times.
Scalable network connection
Featuring an open SFP+ slot, you have the flexibility to make changes as needed just by swapping the module in use, whether it is fiber, copper, or direct attach cables (DAC). The card complies with MSA, allowing use with modules from StarTech.com or 3rd parties that support MSA.
Enhance your existing hardware
The 10Gb network card easily connects via an available x4 PCI Express 3.0 expansion slot. The card is shipped with a standard-profile bracket and includes a low-profile bracket for installation in various types of computer chassis. It supports a wide variety of OSes including Windows, macOS, and Linux.
The PEX10GSFP is backed for 2-years by StarTech.com, including free lifetime 24/5 multi-lingual technical assistance.
- Supports optical fibre cable to span longer distances and provides data transmission rates par excellence between servers and network components
- With the 10GBase-X technology get up to 10Gbps data transfer rate over the supported network cable
- To accelerate IT services, increase data centre efficiency and double your bandwidth without doubling your costs and complexity use this 10Gigabit Ethernet
- Add your computer to your home or office network with this single port 10gigabit ethernet card conveniently
Technical Specifications
Expansion Slot Type | SFP+ |
Total Number of Ports | 1 |
Network Technology | 10GBase-X |
Product Type | 10Gigabit Ethernet Card |
Manufacturer Part Number | PEX10GSFP |
Manufacturer Website Address | http://www.startech.com/au |
Packaged Quantity | 1 |
Manufacturer | StarTech.com |
Product Model | PEX10GSFP |
Product Name | PEX10GSFP 10Gigabit Ethernet Card |
Brand Name | StarTech.com |
Chipset Manufacturer | Marvell |
Chipset Model | AQC100S |
Data Transfer Rate | 1.25 GB/s |
Media Type Supported | Optical Fiber |
Fiber Mode Supported | Multi-mode |
Weight (Approximate) | 53.9 g |
Form Factor | Plug-in Card |
Height | 121.9 mm |
Width | 17.8 mm |
Depth | 94 mm |
