QUICKSCAN QBT2500 2D USB KIT BT BLK

QUICKSCAN QBT2500 2D USB KIT BT BLK

QUICKSCAN QBT2500 2D USB KIT BT BLK

Product Overview

QuickScan QBT2500, Bluetooth, Kit, USB, 2D MP Imager, Black (Kit includes Scanner, Base Station and USB Cable 90A052258)


IMAGING TECHNOLOGY
The market trend towards 2D barcodes has clearly spread across the whole data capture industry. This is particularly true at Retailers' where POS check-out activities face an increased need for 2D scanning and at the same time rely on reading mobile phone displays and loyalty cards.

THE MOST PROMPT RESPONSE AT THE POS CHECK-OUT
The QuickScan 2500 2D imager is your trusted companion at the POS check-out. It knows very well the importance of prompt readings, whatever the barcode, regardless of whether it's hard-to-read, poorly printed or damaged, and it easily scans mobile devices and through plexiglass barriers, all at an incredibly affordable price.

EXTREME PRECISION CONVEYED
A sense of extreme precision is conveyed to the operator at any time, facilitating their job by clearly showing where the scanner is pointing. From the intuitive blue dot of the QW model, you can even get all the extra-precision you need with the outstanding aimer of the QD, QM and QBT models, made of two blue sharply-defined triangles. Datalogic's 'Green Spot' technology then confirms the good read, perfectly centered on the barcode and between the two triangles, backed up by a powerful beeper that can be adjusted to your preferred level of sound. Overall, the soft red illumination lowers fatigue on the operator's eyes.

GO CORDLESS, AT YOUR CONVENIENCE
Featuring narrow band radio communications with Datalogic's STAR Cordless System™ (QM models) or Bluetooth® wireless technology (QBT models), the QuickScan 2500 provides the broadest choice, to best manage delivery even in times of shortage of Bluetooth micro-chips. STAR radio ensures interference-free communication with low sensitivity to obstacles, avoiding delays and increasing productivity, particularly in busy environments with Bluetooth and Wi-Fi. Featuring the distinctive design and family feeling of the Datalogic general purpose handheld scanners, the QuickScan 2500 series offers a variety of stands and accessories to best fit in any in-store environment.

  • Bluetooth technology - Allows compatibility with most of your smart devices
  • With Bluetooth technology, you can scan barcodes and then transmit data from the base
  • Perfect for applications that require direct association with a workstation or a notebook
  • Laser-free design provides high-performance scanning without the risk of eye injury

Technical Specifications

Interfaces/Ports
Host InterfaceUSB
Serial
Network & Communication
BluetoothYes
Radio FrequencyYes
Physical Characteristics
Weight (Approximate)145 g
Form FactorHandheld
Product ColorBlack
Color FamilyBlack
Technical Information
Connectivity TechnologyCable
Light SourceLED
Image FormatsJPEG
TIFF
Scan PatternOmni-directional
Image Sensor TypeImager
Cable Type IncludedUSB
Scanning Capability1D
2D
Reading Angle (Skew)65°
Reading Angle (Pitch)65°
Reading Angle (Roll)360°
Maximum Ambient Light110000 lux
Minimum Print Contrast15%
Minimum Element Resolution (Code 39)0.13 mm
Maximum Element Resolution (Code 39)0.25 mm
Maximum Element Resolution (DataMatrix)0.25 mm
Maximum Element Resolution (PDF417)0.17 mm
General Information
Product TypeBarcode Scanner Kit
Manufacturer Part NumberQBT2500-BK-BTK1
Manufacturer Website Addresshttp://www.datalogic.com
ManufacturerDatalogic S.p.A
Product ModelQBT2500
Product NameQuickScan QBT2500 Barcode Scanner Kit
Product LineQuickScan
Product Series2500
Brand NameDatalogic
Miscellaneous
Application/UsageTicketing
Transportation
Commercial Service
Government
Healthcare
Hospitality
Industrial
Laboratory
Light/Clean Manufacturing
Pharmacy
Retail
Smartphone
Ingress Protection (IP) RatingIP52
