HPE MSA 2062 12Gb SAS LFF Strg
HPE MSA 2062 12Gb SAS LFF Strg
Product Overview
HPE 2062 12 x Total Bays DAS Storage System - 2 x 1.92TB SSD - 2U Rack-mountable - 0 x HDD Installed - 3.84 TB Total Installed SSD Capacity - Serial Attached SCSI (SAS) - 12Gb/s SAS - 12Gb/s SAS Controller - RAID Supported
What's New
- New 6th Gen MSA storage architecture with new HW and SW features including Tiering 2.0, RAID protection scheme (MSA DP+), a new web interface, and data management through a new RESTful interface.
- Improved array performance that provides more IOPS, more bandwidth and expanded backend connectivity.
- Up to 45% increase on IOPS, and up to 60% improvement on sequential throughput vs. MSA Gen5 (depending on host protocol).
- New disk group type (MSA DP+) that increases availability, dramatically decreases RAID rebuild times, improves performance, simplifies setup and provides more granular expansion of disk pools.
Key Features
Affordable Application Acceleration
The HPE MSA 2062 Storage is capable of delivering over 325,000 IOPS for affordable application acceleration for small to medium-sized businesses.
Save 32% on HPE MSA 2062 with all-inclusive software and 3.84 TB of Solid State Drive (SSD) capacity included.
MSA's 'set and forget' Data Services does not Require a Dedicated Storage Administrator to Manage
The HPE MSA 2060 Storage is easy to install, easy to use, easy to maintain, even for an IT generalist. Administrators will find the MSA 2060's new Storage Management Utility intuitive and easy to navigate.
MSA's automated tiering engine dynamically responds to workload changes so you don't have to, insuring the hottest data will be moved to the fastest media automatically and in real-time.
Leverage Data Protection Features to Keep your Business Running in the Event of a Disaster
The HPE MSA 2060 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.
Remote replication via Fibre Channel (FC) or iSCSI facilitates affordable disaster recovery solution.
Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.
Flexible, Modular Architecture that Facilitates Growth into the Future
The HPE MSA 2060 Storage supports a mixture of 3.5 inch LFF and 2.5 inch SFF expansion enclosures for a maximum of 9 (10 including base system) enclosures.
Start small and scale as needed with any combination of SSDs, Enterprise SAS or MidLine SAS HDDs.
Technical Specifications
| Energy Star | Yes |
| Number of Total Expansion Bays | 12 |
| "Number of 3.5"" Bays" | 12 |
| Host Interface | 12Gb/s SAS |
| Number of SAS Ports (External) | 8 |
| Controller Type | 12Gb/s SAS |
| Number of Controllers | 2 |
| RAID Supported | Yes |
| Total Solid State Drive Capacity Installed | 3.84 TB |
| Number of Hard Drives Supported | 12 |
| Number of Hard Drives Installed | 0 |
| Number of Solid State Drive Supported | 12 |
| Number of Solid State Drive Installed | 2 |
| Solid State Drive Configuration | 2 x 1.92TB |
| Clustering Supported | No |
| Weight (Approximate) | 4.99 kg |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 88.9 mm |
| Width | 444.5 mm |
| Depth | 508 mm |
| Product Type | DAS Storage System |
| Manufacturer Part Number | R0Q83A |
| Manufacturer Website Address | https://www.hpe.com/au/ |
| Manufacturer | Hewlett Packard Enterprise |
| Product Model | 2062 |
| Product Name | MSA 2062 12Gb SAS LFF Storage |
| Product Series | 2000 |
| Brand Name | HPE |
