Product Overview
HPE FlexNetwork 5520 HI 24 Ports Manageable Ethernet Switch - Gigabit Ethernet, 10 Gigabit Ethernet - 10/100/1000Base-T, 10GBase-X - 3 Layer Supported - Modular - 31 W Power Consumption - 1.44 kW PoE Budget - Optical Fiber, Twisted Pair - PoE Ports - 1U High - Rack-mountable, Cabinet Mount
HPE FlexNetwork 5520 HI Switch SeriesThe HPE FlexNetwork 5520 HI Switch series delivers superior performance, high availability, and simplified manageability by leveraging advanced features at the access and aggregation layer of medium and large enterprise networks.
These switches deliver faster performance and advanced L3 features with support for larger ARP/MAC tables and Longest Prefix Match (LPM). VXLAN and EVPN enable multitenant isolation and greater scalability; high availability and resiliency provided by Distributed Resilient Network Interconnect (DRNI), Intelligent Resilient Framework (IRF), Virtual Router Redundancy Protocol (VRRP), Equal-Cost Multipath (ECMP) and Bi-directional Forwarding Detection (BFD). Real-time network health, network and switch performance and visibility provided with Intelligent Management Center (IMC) and Intelligent Network Quality Analyzer (iNQA). Support for IPv4/IPv6, OpenFlow, and MPLS/VPLS features provides investment protection and eases transition from IPv4 to IPv6 networks.
- Gigabit Ethernet port for ultra-fast network speeds
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Rack mounting enables you to organize wires & secure cables for professional installation
- Can work as layer 3 routing for scalable network design
- Management capability provides control over setup and configuration of your network
- Supports optical fibre cable to span longer distances and provided high data transmission rates between servers and network components
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Cascade to other network devices through the uplink port to expand your local area network
- Create your own LAN and connect your PC, laptop, printer and other peripherals with the help of 24 ports
- Quickly and easily set up a wired network with 24 networking ports
Technical Specifications
Management & Protocols
| Manageable | Yes |
Miscellaneous
| Environmentally Friendly | Yes |
I/O Expansions
| Expansion Slot Type | SFP+ |
| Number of SFP+ Slots | 4 |
| Shared SFP Slot | Yes |
| Total Number of Expansion Slots | 5.0 |
Media & Performance
| Network Technology | 10/100/1000Base-T |
| 10GBase-X | |
| Ethernet Technology | Gigabit Ethernet |
| 10 Gigabit Ethernet | |
| Media Type Supported | Twisted Pair |
| Optical Fiber |
Network & Communication
| Layer Supported | 3 |
| Networking Standards | IEEE 802.3af |
| IEEE 802.2 | |
| IEEE 802.1w | |
| IEEE 802.1v | |
| IEEE 802.1s | |
| IEEE 802.3x | |
| IEEE 802.3u | |
| IEEE 802.3i | |
| IEEE 802.3az | |
| IEEE 802.3at | |
| IEEE 802.3ah | |
| IEEE 802.3z | |
| IEEE 802.3ab | |
| IEEE 802.3ae | |
| IEEE 802.3ad | |
| IEEE 802.3ac | |
| IEEE 802.1p | |
| IEEE 802.1AX | |
| IEEE 802.1ak | |
| IEEE 802.1ae | |
| IEEE 802.1ad | |
| IEEE 802.1ab | |
| IEEE 802.1r | |
| IEEE 802.1Q |
Interfaces/Ports
| Network (RJ-45) | Yes |
| Modular | Yes |
| Uplink Port | Yes |
| Total Number of Network Ports | 24 |
| Port/Expansion Slot Details | 24 x Gigabit Ethernet PoE+ |
| 1 x Expansion Slot | |
| 4 x 10 Gigabit Ethernet Expansion Slot |
Physical Characteristics
| Weight (Approximate) | 9.20 kg |
| Form Factor | Rack-mountable |
| Cabinet Mount | |
| Height | 43.7 mm |
| Width | 439.9 mm |
| Depth | 460 mm |
| Compatible Rack Unit | 1U |
Power Description
| Power Source | Power Supply |
| Frequency | 50 Hz |
| 60 Hz | |
| Power Consumption | 31 W |
| Number of Power Supplies Supported | 2 |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 1.44 kW |
General Information
| Product Type | Ethernet Switch |
| Manufacturer Part Number | R8M28A |
| Manufacturer Website Address | https://www.hpe.com/au/ |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | FlexNetwork 5520 24G PoE+ 4SFP+ HI Switch |
| Product Line | FlexNetwork |
| Product Series | 5520 HI |
| Brand Name | HPE |
