2-to-1 RJ45 Splitter Cable Adapter - F/M
2-to-1 RJ45 Splitter Cable Adapter - F/M
Product Overview
StarTech.com 2-to-1 RJ45 Splitter Cable Adapter - Network splitter - RJ-45 (M) - RJ-45 (F)~ - Cable for Hub, Switch, Patch Panel - First End: 1 x RJ-45 Network - Male - Second End: 2 x RJ-45 Network - Female - Splitter Cable - 24 AWG - Beige
The RJ45SPLITTER 2-to-1 RJ45 Splitter Cable Adapter increases the number of RJ45 network connections on an RJ45 outlet, allowing two 10/100 Ethernet signals through a single Cat5/Cat5e wire.
On one end of the installation the splitter enables you to connect two patch cables from a hub or switch to a single port on a patch panel; while on the other end of the installation the splitter connects to a single Cat5/Cat5e network drop through a wall outlet which can then be split and connected to two separate devices. The patch panel and wall outlet are connected through a single Cat5/Cat5e cable.
Designed and constructed for maximum durability, this Ethernet Splitter Cable is backed by StarTech.com's Lifetime Warranty.
~- RJ45 SPLITTER
- This RJ45 cable adapter enables two 100Mb network connections from a single 8 wire network connection, without the need to run additional cables
- EASY INSTALL
- RJ45 splitter cable is easy to use and install; Combine two Ethernet ports into one RJ45 wall outlet and then split one Cat 5/5e line back out to two devices through the wall outlet at the other end of the connection
- RELIABLE AND DURABLE
- The RJ45 adapter provides a stable connection for two devices, allowing you to work efficiently without any interruption
- IMPORTANT NOTE
- This adapter cannot be used to split a network connection in two ports; The adapter is meant to be used in pairs, for example to connect 2 devices on the destination side with 2 Ethernet ports on the source side over a single cable run
- THE IT PRO'S CHOICE
- Designed and built for IT Professionals, this RJ45 splitter is backed for life, including free lifetime 24/5 multi-lingual technical assistance~
Technical Specifications
| Weight (Approximate) | 19.8 g |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Product Color | Beige |
| Cable Length | 33.02 cm |
| Conductor | Copper |
| Device Supported | Hub |
| Network Device | |
| Patch Panel | |
| Wall Outlet | |
| Switch | |
| Number of Conductors | 8 |
| Cable Characteristic | Splitter Cable |
| Connector Type on First End | RJ-45 Network - Male |
| Connector Type on Second End | RJ-45 Network - Female |
| Number of Ways | 2-way |
| American Wire Gauge | 24 AWG |
| Product Type | Network Cable |
| Manufacturer Part Number | RJ45SPLITTER |
| Manufacturer Website Address | http://www.startech.com/au |
| Manufacturer | StarTech.com |
| Product Name | 2-to-1 RJ45 Splitter Cable Adapter - Network splitter - RJ-45 (M) - RJ-45 (F) |
| Brand Name | StarTech.com |
