Product Overview
StarTech.com 2-Post 12U Heavy-Duty Wall Mount Network Rack, 19" Open Frame Server Rack with Adjustable Depth, Data Rack for IT Equipment~ - 2-Post 12U open frame network rack with adjustable depth (12-20in) - Durable heavy-duty 19" data server rack - Efficient flat pack shipping and hassle-free installation - M6 cage nuts, screws included - EIA/ECA-310 compliant; Max capacity 200lbs/90kg~
This open-frame wall-mount server rack provides 12U of storage, helping you to save space and stay organized. The equipment rack features an adjustable depth and can hold a total of up to 198 lb. (90 kg).
Easy, hassle-free installation
With adjustable depth to as low as 12 in. (30.5 cm) this network rack is perfect for smaller spaces. It's easy to assemble and features wall-mounting holes that are spaced 12 and 16 in. apart, making it suitable for mounting on almost any wall, based on North American wall-frame stud-spacing standards. The wall-mount rack comes in a flat-pack, which makes it easy to transport and saves you money on shipping.
Accommodate larger devices
The open-frame rack adjusts from 12 to 20 in. (30.5 to 50.8 cm) to accommodate larger data, network, and telecommunication devices. The above-average depth also gives you the option to mount shelves and other accessories.
Free up space
When space is limited you can mount the open-frame rack on a server room wall, office, or above a doorway, to expand your workspace and ensure your equipment is easy to access.
Keep your equipment cool and accessible
The rack's open frame design ensures passive cooling for your rack-mounted equipment. Additionally, the open frame provides easy access to your equipment and makes it easier to configure mounted devices, which saves you time.
~
- Rack Frame allows quick and easy retrieval of your items with better organising and feasible mounting
- Server application, usage offers maximum items, valuables, equipment organisational, storage, placement reliability
- Wall mountable rack frame is Ideal for permanent placement with added space efficiency
- Built with spcc to offer great resistance to damage and deterioration
- Comes in black colour for an elegant and fashionable look
- Adjustable Mounting Rails feature for maximum items, valuables, equipment organisational, storage, placement convenience
Technical Specifications
Assembly Required | Yes |
Weight (Approximate) | 14.60 kg |
Length | 510.5 mm |
Rack Width | 482.60 mm |
Rack Height | 12U |
Height | 640.1 mm |
Width | 502.9 mm |
Maximum Weight Capacity | 90 kg |
Static/Stationary Weight Capacity | 90 kg |
Rack Depth | 508 mm |
Product Color | Black |
Color Family | Black |
Product Material | Steel |
SPCC |
Product Type | Rack Frame |
Manufacturer Part Number | RK12WALLOA |
Manufacturer Website Address | http://www.startech.com/au |
Manufacturer | StarTech.com |
Product Name | 12U Wall Mount Server Rack- Equipment Rack - 12 - 20 in. Depth |
Brand Name | StarTech.com |
Application/Usage | A/V Equipment |
Patch Panel | |
LAN Switch | |
Server | |
Computer | |
Features | Adjustable Mounting Rails |
Rack Type | Open Frame |
Rack Post Quantity | 2 |
